80mm Bill Printers/Thermal Receipt Printer (SGT-80180)

Feature of 80mm Thermal Printer, POS Printer, Receipt Printer,
1. Printing method Direct thermal
2. Resolution 576dots/line or 572dots/line
3. Printing speed 180mm/sec
4. Interface Serial/parallel/USB/LAN
Printing paper 79.5± 0.5mm× φ 83mm
LineSpacing 3.75mm(Use command modifies line spacing)
Column number 58mm paper: FontA-42 olumns or 48 olumns/FontB-56columns or
64columns/Simplified Chinese, traditional Chinese-21columns or 24columns
Character size ANK, FontA: 12× 24dots, FontB: 9× 17dotsSimplified Chinese, traditional Chinese: 24× 24dots
Barcode Character
Extension character sheets PC347(Standard Europe)\Katakana\
PC850(Multilingual)\PC860(Portuguese)\
PC863(Canadian-French)\PC865(Nordic)\
West Europe\Greek\Hebrew\East Europe\Iran\
WPC1252\PC866(Cyrillic#2)\PC852(Latin2)\
PC858\IranII\Latvian\Arabic\PT151(1251)
Barcode types UPC-A/UPC-E/JAN13(EAN13)/JAN8(EAN8)/CODE39/ITF/CODABAR/CODE93/CODE128
Buffer
Input buffer 64k bytes
NV Flash ^^
Cash drawer control DC 24V/1A
Power supply
Power supply Input: AC 110V/220V, 50~60Hz
Power adapter Output: DC 24V/2.5A
Physical characteristics
Weight 1.56kg
Dimension 200× 145× 137mm
Environmental Requirements
Working environment temperature (0~45° C) humidity(10~80%)
Storage environment temperature (-10~60° C) humidity(10~90%)
Lifetime
Reliability 100km
