1.1mm Double Side ITO Coated Glass for Touch Panel

1.1mm double side ITO coated glass for Touch Panel1.Basic Concept:On the surface of the common glass coated with a layer of indium tin oxide conductive film, to form the indium tin oxide glass which common used in LCD, usually referred to as ITO glass. ITO as nanometer indium tin oxide, has good conductivity and transparency, can cut off the harmful electromagnetic radiation, ultraviolet light and far infrared ray to human body. Therefore, after spraying in glass, plastic and electronic display screen, not only keep them to enhance conductivity and transparency and also to cut off harmful electronic radiation, ultraviolet and infrared to human body at the same time. ITO conductive glass is on the basis of the calcium-sodium or borosilicate substrate, using the method of magnetron sputtering plating a layer of indium tin oxide (commonly known as ITO) film. Processing LCD special ITO conductive glass, before plating ITO layer, also plating a 20-30 nm thick layer of silicon dioxide as the barrier layer, the main effect is to prevent the metal ion in the calcium-sodium substrate diffusion penetration to the ITO layer, it will effect the conductivity of ITO layer. High-grade LCD special used ITO glass, in order to get a more uniform display control, before sputtering ITO layer, the substrate glass need to be polished. The advanced ITO coating production line and maturemanagement ofprocessing technology, JMT can produce high and low resistance TN\STN of ITO conductive glass (the minimum 3 ohm ultra-low resistance ITO glass) and the ITO glass for touch screen, optical shadow elimination ITO glass, OGS monolithic (BM + ITO) coated glass, OGS large (BM+ ITO) coated glass, TFT low-temperature ITO coated glass etc.2.Application:ITO conductive glass is widely used in electronics, LCD touch screen products, high-grade products.3.Processing size:14''x14'' \ 14''x16'' \ 300x360mm \300x350mm \370x470mm \400x500mmThickness: 0.4mm—1.1mm (according to customers' requirements)4.Toughened standards:GB/T9963-1998 BS6206 ANSI Z97.1-2004EN12150ITO coated glass for touch panelWhy you choose us?1.National high-tech enterprise2.More than 10 years experience in glass deep processing3.The total assets had exceed RMB 200 million4.50000 square meters of factory buildings5. 5 lines of vacuum vertical line of magnetron sputtering6.Professional electronic appliances supporting glass manufacturer7.Supply the Glass deep processing of the entire process solutionsOur products:Anti-reflective glass : The transmittance can be up to 99% , the reflectivity can be less than 0.5%ITO coated glass : The sheet resistance of ITO coating can be produced from 3 ohms/sq. to 1000 ohms/sq.And we also can produce Anti-glare glass /Anti-fingerprint glass /Diamond surface glass /Strengthened glass screen protectors with silk-printing for display device etc.
