UTP Cat. 5e Inline Coupler (CL-KJ-C5I7)

CL-KJ-C5I7
UTP Cat. 5e Inline Coupler

Main Description of The Product:

1. Type: Cat5e snap-in keystone jack 8P8C Unshielded

2. Termination: 110 style 180 degree punch down for 22-26 AWG solid wire.

3. T568A & TT568B wiring compatible

4. Housing: PC UL94V-0, high temperature thermoplastic

5. Contract: Phosphor bronze, with "3 to 50U" gold plate

6. Accept 22-26 AWG solid with a insulation diameter of 0.4-0.6mm

7. Easy to be terminated Low attenuation loss and high return loss.

Technique Characteristics:

ELECTRICAL:

1. Voltage rating: 125 VAC RMS

2. Current rating: 1.5 AMP

3. Contact resistance: 100 Milliohms MAX

4. Insulation resistance: 1000 Megohms MIN @ 500 VDC

5. Dielectric strength: 750 VAC RMS 60Hz, 1MIN

ENVIRONMENTAL:

1. Storage: -40° TO +85°

2. Operation: 0° TO 70°
