3G HSDPA WCDMA Modem SIM5218 Modem

3G HSDPA WCDMA Modem, SIM5215 Modem, RS232 & USB Interface
UMTS Terminal, whatever supports the HSDPA standard


Moudle introduction:

The SIM5215 series is a Multi-Band WCDMA/GSM/GPRS/EDGE module solution which supports WCDMA 384kbps for data transfer.

With abundant application capability like embedded LUA script, TCP/UDP/FTP/HTTP/HTTPS/SMTP/POP3 and MMS, the module provides much flexibility and ease of integration for customer's application. Its unique camera/video call feature shall add value to security solutions. It is ideal for a wide range of products including AMR, Gateway, Telematics, Tracking solution, Security solution and much more.


General features

* SIM5215A: Dual-Band UMTS/HSDPA 850/1900MHz
Quad-Band GSM/GPRS/EDGE 850/900/1800/1900MHz
* SIM5215E: Dual-Band UMTS/HSDPA 900/2100MHz
Tri-Band GSM/GPRS/EDGE 850/900/1800MHz
* SIM5215J: Dual-Band UMTS/HSDPA 850(800)/2100MHz
Quad-Band GSM/GPRS/EDGE 850/900/1800/1900MHz

* GPRS multi-slot class 12
* EDGE multi-slot Class 12
* WCDMA 3GPP release 99
* Output power
- UMTS 1900/850: 0.25W
- UMTS 2100/900: 0.25W
- GSM850/GSM900: 2W
- DCS1800: 1W
- PCS1900: 1W
* Control Via AT Commands
* Supply voltage range: 3.3V~ 4.2V
* Operation temperature range: -30 ° C to +80° C
* Dimension: 36*26*4.7mm
* Weight: 7g


Support embedded Script Language

* LUA Script Language


Specifications for Data transfer

* WCDMA
- Max. 384Kbps(DL), Max. 384Kbps(UL)
* EDGE
- Max. 236.8Kbps(DL), Max. 118Kbps(UL)
* GPRS
- Max. 85.6Kbps(DL), Max. 42.8Kbps(UL)
* CSD
- GSM data rate 14.4Kbps
- WCDMA data rate 57.6Kbps


Interfaces

* USB2.0
* UART
* USIM card
* ADC
* Digital Camera
* GPIO
* I2C
* Micro-SD card
