GSM 16 Port GPRS Modem Pool Support Bulk SMS

GSM 16 Port GPRS Modem Pool Support Bulk SMS, Quadband (BL16GU)
1. Frequency: Quad band 850/900/1800/1900MHz
2. Function: GPRS/SMS/MMS/, TCP/IP, FTP
3. Built in software

GSM 16 port GPRS modem pool support TCP/IP, FTP, MMS, SMS Open AT
16 port GPRS modem pool basic introduction
ETSI GSM phase 2/2+ standard
Double tone multi-frequency function(DTMF)
SIM application toolkit
Send and receive SMS, MMS, e-mail and voice
Open at and TCP/IP stacks
Maximum transmiting speed: 115.2kbps
Electric interface: ETSI standard
Electric power source: 100/250VAC
Switch independence, support for the size of SIM card(16big/small)
Ports support hot-swapping
GPRS modem pool parameter
Frequency Band: 850/900/1800/1900MHz
Wavecom module: Q24plus, Q2686, Q2687
Simens module: MC55I
Support 16 SIM card/SMA antenna
Support: SMS, MMS, Voice, Fax-depends on module
Support: Windows 2000/Me/XP, SCO UNIX, SCO XEINX, Linux
TCP/IP/UDP/PPP

GPRS Function:
- GPRS multi-slot class 10
- 21.4kbps uplink / 85.6 kbps downlink
- 42.8 kbps uplink / 68.2 kbps downlink
- GPRS mobile station class B
- Full PBCCH support
SMS Function:
- Support AT command
- Text and PDU
- Point-to-point (MT/MO)
- SMS broadcast
Voice Function:
- Voice Call through mobile network
- Auto answer function
- Full duplex and half duplex rate
- Enhanced full rate (EFR)
- Double sound multi- frequencies function (DTMF)
- Basic handsfree operation
- Echo cancellation
- Noise reduction
Data
- CSD up to 18.8 kbps
- Auto answer function
- USSD
- Non transparent mode
- V. 82bis compression
- V. 110
Accessories
- USB cable
- GPRS Modem Pool main unit
- Power Cable
- SMA Antenna x16
- Manual CD
Size: 400*120*130mm
Weight: 6kg
Available Temperature: -40-80° C
Interface: PCI(USB optional)

GPRS modem pool Installation steps:
A. Use power cable to connect device
B. Insert SIM card, make sure chipset connect with card reader
C. Insert PCI card to computer, follow prompts to install driver
D. Turn on power, red LED light, all red light flashing stands equipment begins work.
