High Speed Full Automatic Pet Bottle Blowing Machine 8cavity
- Payment Type:
- L/C, T/T
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
| Place of Origin: | Shenzhen |
|---|---|
| Payment Type: | L/C, T/T |
Product Description
Product Description
Basic data of the blowing bottle production line
Production capacity: 8000-9000bottles/h
Power supply: 380V, 50HZ
Bottle: Raw materials: PET bottle
Brief Introduction
CM- A8L Full automatic blow molding machine is suitable for producing PET plastic containers and bottles in all shapes. It is widely used for producing the carbonated bottle, mineral water bottle, pesticide bottle, oil bottle, cosmetics bottle, and hot filling bottle etc.
Settings:
1). PLC: Mitsubishi/SIEMENS
2). Pneumatic parts: FESTO
3). Operating system: LG
4) Relay: OMRON
5). Infrared thermometer: AMERICA RAYTEK
6). Other electric parts are all world-famous brand
7). Servo motor National (JAPAN)
Machine Features:
1)Reasonable design, full automatically control, save power and labor.
2)Feeding system carries the preforms by robot arms automatically.
3)Infrared oven heater adopts the quartz lamp to heat the PET tube.
4)Fully automatic process with low investment, high efficiency, quick and safe for operation, easy for maintenance.
5)We have perfect service after sales.
6)Adopting high quality components
Configurations:
Items Brand Origin
Air-break switch Mitsubishi Japan
Air-break switch contactor Zhengtai China
Minitype breaker Zhengtai China
Relay OMRON Germany
Thermal overload reply Zhengtai China
Option switch Schneider France
Green directive button Schneider France
Emergency stop switch Schneider France
Normally open contact Schneider France
Normally closed contact Schneider France
Photoelectric switch OMRON Germany
Travel switch OMRON Germany
Proximity switch OMRON Germany
Photoelectric switch OMRON Germany
Transducer FULIN China
Touch screen LG Korea
PLC LG Korea
Technical Parameter:
Model CM-A8L
Productivity Depend on bottle design 8000-10000PCS/H
Product type Body diameter ≤ 90mm
Height ≤ 325mm
Neck diameter 28mm-30mm
Mold Cavity 8cavities
Mold thick 240mm
Main machine power Electrical source power 380v 3Phase /220v 3Phase 50/60HZ
Rated Power 66kw
Really use power 28kw
Air source LP air compressor 2.0m3/min 1.0MPa
HP air compressor 3.2m3/min 3.0MPa x 3
Air dryer 10.0m3/min 3.0MPa
Cooling water Cooling water 60L/min
Size L*W*H 5500*4000*2200mm
Weight 5800kg
Auxiliary equipment(preform unscrambler) L*W*H 2300*1500*2480mm
Weight 350kg
Resin available PET
Production capacity: 8000-9000bottles/h
Power supply: 380V, 50HZ
Bottle: Raw materials: PET bottle
Brief Introduction
CM- A8L Full automatic blow molding machine is suitable for producing PET plastic containers and bottles in all shapes. It is widely used for producing the carbonated bottle, mineral water bottle, pesticide bottle, oil bottle, cosmetics bottle, and hot filling bottle etc.
Settings:
1). PLC: Mitsubishi/SIEMENS
2). Pneumatic parts: FESTO
3). Operating system: LG
4) Relay: OMRON
5). Infrared thermometer: AMERICA RAYTEK
6). Other electric parts are all world-famous brand
7). Servo motor National (JAPAN)
Machine Features:
1)Reasonable design, full automatically control, save power and labor.
2)Feeding system carries the preforms by robot arms automatically.
3)Infrared oven heater adopts the quartz lamp to heat the PET tube.
4)Fully automatic process with low investment, high efficiency, quick and safe for operation, easy for maintenance.
5)We have perfect service after sales.
6)Adopting high quality components
Configurations:
Items Brand Origin
Air-break switch Mitsubishi Japan
Air-break switch contactor Zhengtai China
Minitype breaker Zhengtai China
Relay OMRON Germany
Thermal overload reply Zhengtai China
Option switch Schneider France
Green directive button Schneider France
Emergency stop switch Schneider France
Normally open contact Schneider France
Normally closed contact Schneider France
Photoelectric switch OMRON Germany
Travel switch OMRON Germany
Proximity switch OMRON Germany
Photoelectric switch OMRON Germany
Transducer FULIN China
Touch screen LG Korea
PLC LG Korea
Technical Parameter:
Model CM-A8L
Productivity Depend on bottle design 8000-10000PCS/H
Product type Body diameter ≤ 90mm
Height ≤ 325mm
Neck diameter 28mm-30mm
Mold Cavity 8cavities
Mold thick 240mm
Main machine power Electrical source power 380v 3Phase /220v 3Phase 50/60HZ
Rated Power 66kw
Really use power 28kw
Air source LP air compressor 2.0m3/min 1.0MPa
HP air compressor 3.2m3/min 3.0MPa x 3
Air dryer 10.0m3/min 3.0MPa
Cooling water Cooling water 60L/min
Size L*W*H 5500*4000*2200mm
Weight 5800kg
Auxiliary equipment(preform unscrambler) L*W*H 2300*1500*2480mm
Weight 350kg
Resin available PET
