Solar Traffic Signal

Solar Traffic Signal
Solar Traffic Signal
Housing Structure of 2mm thick galvanized cold rolling plate, the high precision CNC machining, To ensure high strength,
Accuracy, smoothness and reliability requirements, and electrostatic sprayProcessing technology, has can prevent exposure,
Rain, soil, dust, corrosive gas;

(RedFull Ball): 165LED, (Power): ≤ 5W. (Yellow Full bal): 165LED, (Power): ≤ 5W.
(Yellow Full bal): 120LED, (Power): ≤ 5W. (Ambient Humidity): 5%~95%
(Working Temperature): -25~+60 (Working Drive Mode): (Contant Current)
(Housing body material): 2mm 2mm Ferroalloy (IP Rate): IP54
MTBF: ≥ 5000(Hours) (Wind resistance): 40m/s
(Product Size): 600mm*600mm*3000mm (Lamp Normal working life): ≥ 10
(Maximum output Power of Solar panel): 100W*2
(Solar peak current): 11.2A (Output voltage of solar panel): 18V
(Capacity of lead acid battery): 260AH/12V (Normal service life of battery): ≥ 2 Year
(Working mode: Continuous working): (continuous working)
(Working Voltage): 18V
The built-in independent intelligent signal controller
