D Terminal 14 Pin Connector Cable
- Payment Type:
- L/C, T/T, D/P, Paypal, Money Gram, Western Union
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
| Place of Origin: | Shenzhen China |
|---|---|
| Payment Type: | L/C, T/T, D/P, Paypal, Money Gram, Western Union |
Product Description
Product Description
D Terminal Connector 14pin Cable
Feature:
A series of high density connector with 1.27mm (0.050") spacing.
Suitable for Cable end.
Conforms to the American National Standards Institute ( ANSI) specifications.
Choice of bracket configurations includes: Without rails and latch, and with latch only.
All plastic type available in 14, 20, 26, 36, 50, 50, 68 positions.
Insulator is made of polyester resin and glass fiber reinforced (UL 94-0) providing superior heat and chemical resistance.
Application to miniaturized electronic equipment such as personal computers, facsimiles and other OA equipment.
Recognized UL under the component program of Underwriters Laboratories Inc. File No. E112081.
Electrical:
Rated Current: 1 AMP
Insulation Resistance: 500M ohms min.
Contact resistance: 35 m ohms max.
Dielectric Withstanding Voltage: AC 250V (for 1 minute).
Operating Temperature: -25 ~ +85
Mechanical:
Insulator Material: PBT with glass-fiber reinforced(UL 94V-0).
Contact material: Phosphor bronze.
Feature:
A series of high density connector with 1.27mm (0.050") spacing.
Suitable for Cable end.
Conforms to the American National Standards Institute ( ANSI) specifications.
Choice of bracket configurations includes: Without rails and latch, and with latch only.
All plastic type available in 14, 20, 26, 36, 50, 50, 68 positions.
Insulator is made of polyester resin and glass fiber reinforced (UL 94-0) providing superior heat and chemical resistance.
Application to miniaturized electronic equipment such as personal computers, facsimiles and other OA equipment.
Recognized UL under the component program of Underwriters Laboratories Inc. File No. E112081.
Electrical:
Rated Current: 1 AMP
Insulation Resistance: 500M ohms min.
Contact resistance: 35 m ohms max.
Dielectric Withstanding Voltage: AC 250V (for 1 minute).
Operating Temperature: -25 ~ +85
Mechanical:
Insulator Material: PBT with glass-fiber reinforced(UL 94V-0).
Contact material: Phosphor bronze.
