Mdr 26pin connectors for cable
Feature:
A series of high density connector with 1.27mm (0.050") spacing.
Suitable for Cable end.
Conforms to the American National Standards Institute ( ANSI) specifications.
Choice of bracket configurations includes: Without rails and latch, and with latch only.
Insulator is made of polyester resin and glass fiber reinforced (UL 94-0) providing superior heat and chemical resistance.
Application to miniaturized electronic equipment such as personal computers, facsimiles and other OA equipment.
Recognized UL under the component program of Underwriters Laboratories Inc. File No. E112081.
Electrical:
Rated Current: 1 AMP
Insulation Resistance: 500M ohms min.
Contact resistance: 35 m ohms max.
Dielectric Withstanding Voltage: AC 250V (for 1 minute).
Operating Temperature: -25 ~ +85
Mechanical:
Insulator Material: PBT with glass-fiber reinforced(UL 94V-0).
Contact material: Phosphor bronze.
Feature:
A series of high density connector with 1.27mm (0.050") spacing.
Suitable for Cable end.
Conforms to the American National Standards Institute ( ANSI) specifications.
Choice of bracket configurations includes: Without rails and latch, and with latch only.
Insulator is made of polyester resin and glass fiber reinforced (UL 94-0) providing superior heat and chemical resistance.
Application to miniaturized electronic equipment such as personal computers, facsimiles and other OA equipment.
Recognized UL under the component program of Underwriters Laboratories Inc. File No. E112081.
Electrical:
Rated Current: 1 AMP
Insulation Resistance: 500M ohms min.
Contact resistance: 35 m ohms max.
Dielectric Withstanding Voltage: AC 250V (for 1 minute).
Operating Temperature: -25 ~ +85
Mechanical:
Insulator Material: PBT with glass-fiber reinforced(UL 94V-0).
Contact material: Phosphor bronze.
