Servo Driver (AG2030RB)

Servo Driver / Servo System (AG2030RB)

— Rated power: 7.5---75KW
— Rated current: 10~160A
— Control mode: Close loop torque control: Encoder or resolver
— Input voltage: 3 x 380V AC± 15%
— Output frequency: 0--400Hz
— Torque limit: Drive current 180%, braking current 150%
— IP code: IP20
— Overloading multiple: 2.5 multiples
— Braking unit: Built-in
— Protection functions: Overheating, overcurrent, overvoltage
— Sensor: 1 path(4~20mA)/(0~10V)/optional
— Can: 1 path
_ Mode connector: 1 path(RS232)
— Motor Fitting: Synchronous motor
— Motor temperature control & detect mode: PTC
Components: Braking resistor, pressure sensor, cable line, cable of resolver, etc.
