GS-Ms/R Medium-Intensity Dual Solar Aviation Obstruction Light

GS-MS/R Medium-intensity Dual Solar Aviation Obstruction Light

 Advantage
1. International advanced solar panel reaching at least 10 years service life.
2. Comprehensive protection in voltage short, overvoltage, floating Charge and temperature.
3. Low power consumption profession flash switch.
4. international-advanced cold LED with low power consumption, high brightness and service life of light source reaching 100000hours.
5. Strong impact lamp shape with PC material.
6. Strong corrosion resistance, Shock and Vibrations protection and UV protection.
7. At least 7 days autonomy. (optional 15days)
8. Having lightning-protection function.
9. Side open of battery box can be open for maintenance convenience very easily.
10. New technology application. Light can work all day automatically by solar panel which is equal to photocell sensor.

Function
GS-MS/R Medium-intensity Dual Solar Aviation Obstruction Light is single solar light. Installed in the fuse, it can control flash all day automaticly by Solar panel which is equal to photocell sensor. Side on battery box can be opened to be convenient for maintenances. At night, Red Flashing mode, 20 to 60 times/minutes, 2, 000cd; During the day, White Flashing mode, 20 to 60 times/minutes, 20, 000cd.

Scope of Application
GS-MS/R Medium-intensity Dual Solar-Powered Aviation Obstruction Light can be provided with power supply without power transmission cables by solar power, so it is suitable for those locations especially, Electric Tower, High-rise Building, High Chimney, marking towers (Telecom, GSM, Microwave & TV), High Pole, Tower Crane, Wind Tubine, etc etc which are hard to lay the cable or lack of power supply as well as those facilities which have high requirements on lightning protection.

Main Parameter
1. Mode: GS-MS/R
2. Standard: FAA L-864 & L-865(AC 70/7460-1 & AC 150/5345-43 F) or ICAO Annex 14
3. Light intensity: 2, 000cd(At night), 20, 000cd(During the day)
4. Flash rate: 20times/minute(At night); 40times/minutes(During the day)
5. Light Source: LED
6. Service life of LED: 100, 000hours
7. Operating voltage: DC12V(Solar powered Way)
8. Power Consumption: 40W
9. Overall Size(mm): 490 by 490 by 525
10. Installation Size(mm): 322 by 200 by 12
11. Weight: 16Kg
12. Emitting Color: Red(At night) & White(During the day)
13. Ambient Temperature: -50degree centigrade to +70degree centigrade
14. Wind load: 80m/s

Dimension Drawing


Product Picture

Product Application
Product Profile
1. Model: GS-MS/R
2. Applications: Applied to High-rise Building, High Chimney, marking towers (Telecom, GSM, Microwave & TV), High Pole, Tower Crane, Wind Tubinebridge. large-scale port machinery, large engineer machinery and wind turbines.
3. Standard: ICAO Type B & Type A Medium intensity, FAA L-864 & L-865
4. Certificate: CAAC Certificate(ICAO Certificate)
5. Improve Records: None
6. Fault Records: None
7. Quantity/Delivery Day: 20 pcs / 15 Days
