GS-MS/D Medium-intensity Double Solar Aviation Obstruction Light

Advantages
1. International advanced solar panel reaching at least 10 years service life.
2. Comprehensive protection in voltage short, overvoltage, floating Charge and temperature.
3. Low power consumption profession flash switch.
4. International-advanced cold LED with low power consumption, high brightness and service life of light source reaching 100000hours.
5. Strong impact lamp shape with PC material.
6. Strong corrosion resistance and UV protection.
7. At least 7 days autonomy. (optional 15days)
8. Having lightning-protection function.
9. Side open of battery box can be open for maintenance convenience very easily.
10. New technology application. Light can work at night automatically by solar panel which is equal to photocell sensor.
11. Coverting between Main Bulb and Standby Bulb automatically.

Function
GS-MS/D Medium-intensity Double Solar-Powered Aviation Obstruction Light is double solar light. Installed in the fuse, it can control flash automatically when ambient brightness is lower than 50cd/m². This product can work at night and close during the day automatically by Solar panel which is equal to photocell sensor. Side on battery box can be opened to be convenient for maintenances. There are two bulbs for this double light. One bulb works, the other is for standby. When main bulb is broken, standby bulb will work automically.

Scope of Application
GS-MS/D Medium-intensity Double Solar-Powered Aviation Obstruction Light can be provided with power supply without power transmission cables by solar power, so it is suitable for those locations, eg. Electric Tower, Telecom Tower, High-rise building, High chimney, High Pole, etc especially which are hard to lay the cable or lack of power supply as well as those facilities which have high requirements on lightning protection.

Main Parameter
1. Mode: GS-MS/D
2. Standard: FAA L-864/L-885 or ICAO Annex 14
3. Light intensity: 2000cd(± 25%)
4. Flash rate: 20 to 60times/minute
5. Light source: LED
6. Service life of LED: 100, 000hours
7. Operating voltage: DC12V(Solar powered Way)
8. Power Consumption: 30W
9. Overall Size(mm): 525 by 490 by 490
10. Installation Size(mm): 200 by 322 by M10
11. Weight: 20Kg
12. Emitting Color: Red
13. Ambient Temperature: -40degree centigrade to +60degree centigrade
14. Wind load: 80m/s

Dimension Drawing

Product Pictures

Product Profile
1. Model: GS-MS/D
2. Applications: Applied to High-rise Building, High Chimney, High-rise building, Marking towers (Telecom, GSM, Microwave & TV), High Pole, Tower Crane, Wind Tubinebridge, large-scale port machinery, large engineer machinery and wind turbines, etc.
3. Standard: ICAO Medium-intensity Type B, FAA L-864
4. Certificate: CAAC Certificate(ICAO Certificate)
5. Improve Records: None
6. Fault Records: None
7. Quantity/Delivery Day: 100pcs / 15 Days
