GS-LS/S Low-Intensity Single Solar Powered Aviation Obstruction Light

GS-LS/S Low-intensity Single Solar-Powered Aviation Obstruction Light

Advantage
1. PC material with good impact protection strength, thermal stability, high transmittance.
2. Bird spike against bird drop.
3. International advanced solar panel reaching at least 10 years service life.
4. Comprehensive protection in voltage short, overvoltage, floating Charge and temperature.
5. New technology application. Light can work at night automatically by solar panel which is equal to photocell sensor.
6. International-advanced cold LED with low power consumption, high brightness and service life of light source reaching 100000hours.
7. Major Maintenance Cost Saving, Surge protection device inside light.
8. Strong corrosion resistance, Shock and Vibrations protection and UV protection.
9. At least 7 days autonomy. (optional 15days)
10. Movable Panel for being convenient for customer choosing angle.
11. 3/4 inches installation way especially for tower or flag-pole installation way.

Function
GS-LS/S Low-intensity Single Solar-Powered Aviation Light has one solar panel which is equal to photocell and threaded bolt for grounding. Panel angle can be changed from 15 degree to 30 degree, lateral panel base. Installed in the fuse, it can work alone automatically at night when ambient brightness is lower than 500cd/m2.

Scope of Application
GS-LS/S Solar-Powered Aviation Light can be provided with power supply without power transmission cables by solar power, so it is suitable for those locations especially which are hard to lay the cable or lack of power supply as well as those facilities which have high requirements on lightning protection.

Main Parameter
1. Mode: GS-LS/S
2. Standard: FAA L-810, ICAO Annex 14
3. Light intensity: More than or equal to 32.5cd
4. Flash rate: Constant mode or Flash mode(20-60times/minute)
5. Light source: LED
6. Service life of LED: 100, 000hours
7. Operating voltage: DC12V(Solar powered Way)
8. Power Consumption: 6W
9. Overall Size(mm): 350 by 410 by 425
10. Installation Size: 3/4inches
11. Weight: 7.3Kg
12. Emitting Color: Red
13. Ambient Temperature: -40degree centigrade to +60degree centigrade
14. Wind load: 80m/s
15. Protection Standard: IP65

Dimension Drawing



Product Picture


Product Application

Product Profile
1. Model: GS-LS/S
2. Applications: Applied to High-rise Building, High Chimney, marking towers (Telecom, GSM, Microwave & TV), High Pole, Tower Crane, Wind Tubinebridge. large-scale port machinery, large engineer machinery and wind turbines.
3. Standard: ICAO Low intensity Type B, FAA L-810
4. Certificate: CAAC Certificate(ICAO Certificate)
5. Improve Records: None
6. Fault Records: None
7. Quantity/Delivery Day: 100pcs / 3Days
