GS-Hi/O LED High-Intensity Type a LED Obstruction Light

GS-HI/O LED High-intensity Type A LED Obstruction Light

 Advantage
1. Strong efficiency transmission.
2. Omnidirectional LED High-intensity Light.
3. International-advanced Big power and Precision integrated chip LED with high brightness and service life of light source reaching 100000hours.
4. The circuit of the light has surge protection whose lightning proof ability is In 7.5KA/5 times, IMAX 15KA so that the light is suitable to harsh environment.
5. Strong corrosion resistance, Shock and Vibrations protection and UV protection.
6. Baked advance aluminum alloy Material.
7. Resistant to heavy rain or storms and corrosion.
8. Automatically changing light intensity, day/twilight/night intensity operating.
9. More than 91% utilizing rate of illuminating efficiency.
10. Perfect protection function in control circuit. Light will stop working automatically under condition of light short circuit, overtemperature and working exceptional. After fault is solved, control circuit will automatically resume to work normally.

Function
GS-Hi/O LED High-Intensity Type A LED Obstruction Light is one Single light with photocell, so it can work all day and automatically change light intensity according to ambient brightness by photocell. When ambient brightness is less than 50cd/m², light intensity is 2, 000cd(±25); When ambient brightness is between 50cd/m² and 500cd/m², light intensity is 20, 000cd(±25); When ambient brightness is more than 500cd/m², light intensity is 200, 000cd(±25). All control signal wire of light is paralleled to make several lights flash synchronously.

Range of Application
GS-HI/O LED High-Intensity Type A LED Obstruction Light is mainly used on the top of Television transmitting tower, High-rise building, High chimney, cable stayed bridge, communications Tower, Cooling tower, etc which height is over 150meter so that it can play a warning role in potentially hazardous obstructions to air traffic flashing white safety light.

Main Parameter
1. Mode: GS-HI/O
2. Standard: FAA L-856, ICAO Annexure 14, Type A High-intensity
3. Light intensity:
-2000cd(At night, <50 cd/m2)
-20, 000cd(Twilight, 50~500cd/m2)
-200, 000cd(During the day, >500cd/m2)
4. Flash rate: 40-60times/minute
5. Light source: LED
6. Service life of light source: 100, 000 hours
7. Operating voltage: AC220V (option voltage, eg. AC120V, AC110V, DC48V)
8. Power Consumption: 150W
9. Overall Size(mm): 245 by 245 by 400
10. Installation Size(mm): 180 by 180 by 12
11. Weight: 14Kg
12. Emitting Color: white
13. Ambient Temperature: -55 degree centigrade~+70 degree centigrade
14. Wind load: 80m/s
15. Protection Standard: IP67

Dimension Drawing

Product Profile
1. Model: GS-HI/O
2. Applications: Applied to High-rise Building, High Chimney, marking towers (Telecom, GSM, Microwave & TV), High Pole, Tower Crane, Wind Tubinebridge. large-scale port machinery, large engineer machinery and wind turbines.
3. Standard: ICAO Type A High intensity and FAA L-856
4. Certificate: CAAC Certificate(ICAO Certificate) and FAA Certificate
5. Improve Records: None
6. Fault Records: None
7. Quantity/Delivery Day: 20 pcs / 20 Days
