GS-HP/F LED Flood Heliport Light

GS-HP/F LED Flood Heliport Light

Brief introduction
GS-HP/F Flood light adopts whole-seal aluminum shell. Protection standard is IP65. Light source uses LED with high-efficiency and low-consumption, which has wide viewing angle, illumination uniformity angle. The photocell uses imported high-quality component with low static power consumption (lower than 0.5W). This kind of flood light can be widely used outdoors, especially used in the base station.

Characteristics
Visual angle of GS-HP/F Flood Helipad light is larger than 150. Light source efficiency is higher than 100Lm/W and service life is more than ten years.

Scope of Application
It can be widely used in broadcasting, television, microwave, cellphone station, wall light, garden light and road light.

Technical Parameter
1. Power supply: DC48V or AC220V(Option Voltage)
2. Power consumption: 30W
3. Luminous flux: more than or equal to 3600Lm
4. Switch way: light will work when light is on power.
5. Connecting Way: external way
6. static power consumption: less than or equal to 0.5W
7. Ambient temperature: - 55 degree centigrade to +55 degree centigrade
8. Overall dimension(mm): 225 by 185 by 130
9. Installing dimension: 80mm/18*8.5
10. Protection standard: IP65
11. Weight: 1.9kg

Product Application

Product Profile
1. Model: GS-HP/F
2. Applications: Applied to Helipad field, broadcasting, television, microwave, cellphone station, wall light, garden light and road light, etc for illumination.
3. Standard: ICAO Annex 14
4. Certificate: CAAC Certificate(ICAO Certificate)
5. Improve Records: None
6. Fault Records: None
7. Quantity/Delivery Day: 20 pcs / 10 Days
