GS-HP/W Helipad Wind Cone

GS-HP/W Helipad Wind Cone

Description
Helipad Wind Cone is used for indicating final approach and taking off wind direction. According to ICAO requirement, every helipad field must have at least one wind cone. Installation position must be not interfered by around object and airflow formed by helipad wing and make pilot recognize wind cone at 200meter clearly. GS-HP/W illumination wind cone is one sign for all kinds of airports and helipad felids and can work all day. Product standard is compliance with requirement FAA, AC150/5345-27C, L-806 and ICAO.

Application
Helipad Wind Cone is used in airport and helipad fields for indicating final approach and taking off wind direction.

Character
1. Wind sock is made of corrosion resistance and high temperature resistance PVC material.
2. -1pcs LED Aviation obstruction light on top and 2pcs 12W LED flood light for illumination. (Height of Wind Cone is less than 4 meter)
    -1Pcs LED Aviation obstruction light on top and 4Pcs 12W LED flood light for illumination. (Height of Wind Cone is equal to or more than 4 meter)
3. Pole is made of light, strong corrosion resistance SUS 304 Stainless steel.

Main Parameter
1. Height of wind Cone: 1.5meter, 2.5meter, 3.5meter, 4 meters, 5meter, 6meter, 7meter, etc.
2. Operating voltage: AC220V, 50/60 Hz(Option voltage, eg. AC120V, DC48V)
3. Two kind of wind sock:
- 1.2 meter length, big diameter is 300mm, small one is 150mmm(Height of Wind Cone is less than 4 meter)
- 2.4 meter length, big diameter is 600mm, small one is 300mmm. (Height of Wind Cone is between 4meter and 6meter)
- 3.6 meter length, big diameter is 900mm, small one is 450mmm. (Height of Wind Cone is more than 6meter)
Color: red and white or orange and white.
4. Max wind load: 260km/h.

Product Pictures

Product Application

Product Profile
1. Model: GS-HP/W
2. Applications: Applied to Helipad field, broadcasting, television, microwave, cellphone station, wall light, garden light and road light, etc for illumination.
3. Standard: ICAO Annex 14 and FAA
4. Certificate: CAAC Certificate(ICAO Certificate)
5. Improve Records: None
6. Fault Records: None
7. Quantity/Delivery Day: 20 pcs / 10 Days
