GS-MI/C Medium-Intensity Type C Aviation Obstruction Light

GS-MI/C Medium-intensity Type C Aviation Obstruction Light


Application
Medium-intensity Type C Aviation Obstruction Light used in Tower Crane, Wind Turbine, High Mast, Metallurgies, Towers(Telecom, GSM, Electric), Smokestacks, High-rise Buildings and any other potentially hazardous obstructions between 45m and 105m to air traffic with steady-burning red safety light.

Advantages
1. Good impact protection strength, thermal stability, high transmittance.
2. Built-in circuit protect LED, extremely reliable and cost saving.
3. Shockproof and corrosion resistant. Working environment temperature : -40ºC ~ +60ºC.It can be used in very poor conditions .
4. LED is special red color for Aviation Obstruction Light, Typical LED lifetime is more than 100,000 hours.
5. Resistant to heavy rain or storms and corrosion.
6. Free maintenance and aluminum alloy Material.
7. 95% less power consumption than incandescent light
8. Dawn to Dusk operating: Built-in photocell can let light work automatically at night, closed during the day.

Main Parameter
1.Mode:GS-MI/C
2.Standard: ICAO (Aerodromes Annex 14) Medium-intensity Type C
3.Light intensity:2,000cd ±25%
4.Flash rate: Steady-burning way
5.Light source: LED
6.Service life of LED:≥100,000hours
7.Operating voltage:AC220V (option voltage,eg.AC120V,AC110V,DC48V)
8.Power Consumption:30W
9.Overall Size(mm):φ245 by 210
10.Installation Size:φ180 by M10
11. Vertical degree: 3°
12. Horizontal degree: 360°
13. Material:
-Housing: PC
-Base: die casting aluminum
14.Weight:3Kg
15.Emitting Color: Aviation red
16.Ambient Temperature:-40ºC~+60ºC
17.Wind load: 80m/s
18. Protection Standard: IP65

Dimension Drawing

Product Profile
1. Model: GS-MI/C
2. Applications: Applied to High-rise Building, High Chimney, marking towers (Telecom, GSM, Microwave & TV), High Pole, Tower Crane, Wind Tubinebridge. large-scale port machinery, large engineer machinery and wind turbines.
3. Standard: ICAO Medium intensity Type C, FAA L-864
4. Certificate: CAAC Certificate(ICAO Certificate)
5. Improve Records: None
6. Fault Records: None
7. Quantity/Delivery Day: 100pcs / 15 Days
