GS-LI/D Low-Intensity Double Aviation Obstruction Light

Get Latest Price

Payment Type:: T/T, Western Union

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Shenzhen, China
Payment Type:	T/T, Western Union

Product Description

GS-LI/D Low-intensity Double Aviation Obstruction Light

Application

Obstruction light used in Tower Crane, Wind Turbine, High Mast, Metallurgies, Towers(Telecom, GSM, Electric), Smokestacks, High-rise Buildings and any other potentially hazardous obstructions within 45 meter to air traffic with a steady burning red safety light.

Advantages

1.PC material with good impact protection strength, thermal stability, high transmittance.

2. Bird spike against bird drop.

3. International-advanced cold LED with low power consumption, high brightness and service life of light source reaching 100000hours.

4. LED based on obstruction light last 15 times longer than traditional light source, incandescent light.

5. About 96% less power than 116W incandescent light.

6. Major Maintenance Cost Saving, Surge protection device inside light.

7. Strong corrosion resistance, Shock and Vibrations protection and UV protection.

8. Dawn to Dusk operating: Built-in photocell can let light work automatically at night, closed during the day.

9. Free maintenance and 3/4 inches or 1inches installation size being suitable for flag-pole or tower installation way.

10. There is one switch converting between Flash mode and Steady-burning way.

11. Five Years Warranty Period.

Main Parameter

1.Mode: GS-LI/D

2.Standard: ICAO (Aerodromes Annex 14) Low-intensity Type A or Type B and FAA L-810

3.Light intensity: ≥32.5cd(Option 10cd,50cd,80cd,100cd)

4.Flash rate: Steady-burning or Flashing (20-60times/minute)

5. Working way of two lights:

-Two light flashing by Main-standby way, Two lights flashing at the same time or two lights flashing 1.5 second interval.(Flash mode, three ways)

-Two light working by Main-standby way, Two lights working at the same time.(Steady-burning way, two ways)

6.Light source: LED

7.Service life of LED:≥100,000hours

8.Operating voltage:AC220V (option voltage,eg.AC120V,AC110V,DC48V)

9.Power Consumption:4W

10.Overall Size(mm):258 by 136 by 320

11.Installation Size:3/4inches or 1 inches

12. Vertical degree: ≥10°

13. Horizontal degree: 360°

14. Material:

-Housing: PC

-Base: die casting aluminum

15.Weight:2Kg

16.Emitting Color: Aviation red

17.Ambient Temperature:-40ºC~+70ºC

18.Wind load: 80m/s

19. Protection Standard: IP65

Dimension Drawing

Product Pictures

Product Application

Product Profile
1. Model: GS-LI/D
2. Applications: Applied to High-rise Building, High Chimney, High-rise building, Marking towers (Telecom, GSM, Microwave & TV), High Pole, Tower Crane, Wind Tubinebridge, large-scale port machinery, large engineer machinery and wind turbines, etc.
3. Standard: ICAO Low-intensity Type B, FAA L-810
4. Certificate: CAAC Certificate(ICAO Certificate)
5. Improve Records: None
6. Fault Records: None
7. Quantity/Delivery Day: 100pcs / 3 Days
