Wireless Infrared Detector (YX-IRD)

Wireless infrared detector
6.1.1 Wireless infrared detector
The detector adopts high-stable sensor and advanced signal analysis technology. It has strong detecting and against false positives function. When the security area is triggered, it will detect the activity in the security area and send message to the host. The detector is widely used at home, apartment, factory, warehouse, shop, office and so on.
(1) Technical data
Power supply: DC9V battery/DC12V 300mA power supply
Working frequency: 315MHz
Encoding mode: Fixed code
OSC resistor: 4.7MΩ
Modulation: ASK
Standby current: ≤ 70uA
Working current: ≤ 35mA
Low power indication: ≤ 7V
Detecting distance: 8~12m(25)
Detecting angle:
Curtain infrared: 100° H 10° H
Infrared: 110° H 60° V
(2) Installation
1) Put the detector in the security area.
2) The detector is used in indoor area, 2~2.5m height over the ground, and far with air conditioner, refrigerator, and fireplace.
3) The detector is better to be installed same level to the windows for best detecting effect.
4) The tangent detecting effect is much better than radial direction detecting.
(3) Pairing
Login the smart home system through tablet PC. Enter the settings "SystemDefense zone" select one defense zone and write in the basic information, after press "Get address" button, power on the PIR (the PIR will send a testing signal when power on) or trigger it, the host receives the RF signal and read the code out.
