P31, 25 Street Billboards Advertising Full Color LED Display

Get Latest Price

Payment Type:: L/C, T/T, Western Union

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Shenzhen
Payment Type:	L/C, T/T, Western Union

Product Description

Specifications
We are specialized on Billboards Advertising LED Display
1. Relatively low cost.
2. CE, RoHS, FCC, ISO9001.
3. Good after sales service
4. Warranty: 5 years
5. High brightness,
6. Contact for more information.
Advantage
1. Richest Color: with three basic colors (red, green and blue), 256 levels of each color, forming 16777216 kinds of colors.
2. Adjustable brightness.
3. DOT-to-DOT color/ brightness Correction system
4. Fully Customization Design
5. DOT Detection Function

Pixel pitch	31.25mm
Size of module	250mmx250mm
Density of pixel	1024dots/m2
Pixel constitution	4R2G2B
LED Encapsulation	DIP546
Resolution of Module	8*8
Power Consumption of Module	≤ 22W
Maximum power consumption	400W/sqm
The Optimum Viewing Distance	39-104m
Driving IC	MBI5024/ MBI5041
Material	Iron/ Aluminum
Size of cabinet	1000mmx1000mm
Resolution of Cabinet	32*32
Driving method	Static scan constant current
Power supply Brand	Meanwell
Control system	Linsn/ZDEC/DBstar
Refresh rate	≥ 800Hz(Linsn) ≥ 1920Hz(ZDEC)
Frame Frequency	≥ 60Hz
Luminance of white balance	≥ 4000cd/m2
Working environment temperature	below 30° C~60° C
Working Voltage	220V± 10% or 110V± 10%
Grey Scale	Each color≥ 16384 grace
Brightness Adjustment	256 levels of each color automatically, 100 levels of each color manually.
Input signal	RF, S Video, HDMI, DVI etc.
Mean Time Between Failure	> 5000 hrs
Life Span	> 100000 hrs
Out-of-control Rate	< 0.0001
Transmission Distance	Within 100m, network transmission is applied; If a relay is added, then 100m longer. Optical fiber transmission: single mode fibre≤ 15KM, multimode fiber≤ 500m
