Product Description

Full automatic tripod turnstile
1. Stainless steel housing
2. Bi-direction passing, the arm can rotate from one direction or two directions(optional)
3. Adjustable working mode, can be two way passing or one way passing, and the other is prohibited
4. Arms auto drop when power off
5. Arms auto rise up when power on and auto drop on obstacle
6. Traffic light indicator
7. Wingen 26/Dry contact, is compatible with smart card for access control
8. Photoelectric inspection
9. If the passenger does not pass in valid time, the passage will lock up, and the valid time is adjustable
10. Passenger counter.

Technology data
11. Power supply/frequency: AC220V±10%, 50HZ
12. AC110± 10%, 60HZ
13. Working voltage: DC12V
14. Rated power:50W
15. Working temperature: -25ºC~+55ºC
16. Relative humidity: ≤90%
17. Motor speed: 850 times/minute
18. Dimension: bridge: 1235*280*100 type: WJ-TS112
19. Vertical: 420*330*980 type: WJ-TS122
20. Length: 490mm
21. MAX boom endurable: 80kg
22. Boom working force: 4kg
23. Working environment: inner and outer
24. Flow speed: 25~30/minute
25. Input interface: +5V electric level signal or >100ms impulse signal, drive current >10mA, dry contact (COM NO).
26. EM signal interface, dry contact (COM NO)..
27. Alarm input interface:DC12V
28.
29.

Model Item	WJTS122	WJTS110	WJTS112	WJTS111	WJTS122s	WJTS110s	WJTS112s	WJTS111s
Manual, semi or full automatic	Full-automatic				Semi-automatic
Material of housing	304 stainless steel			Iron with powder	304 stainless steel			Iron with powder
Dimension of housing	4203801000	12352801000	12352801000	4203801050	480330980	1200280980	1200280980	4203801050
Thickness of housing	1.5mm				1.5mm
Length of pole	490mm				490mm
Net weight	50kg	70 kg	70 kg	45 kg	40 kg	70 kg	70 kg	35 kg
Max load-bearing of pole	80kg				80kg
Driving force of pole	3kg				3kg
Rotating direction	Double direction				Double direction
Power supply	220V±10%, 110± 10%				220V±10%, 110± 10%
Frequency	50/60HZ				50/60HZ
Working voltage of motor	DC12V				DC24V
Rated power	50W				36W
Driving motor	Brush DC motor				Brushless DC motor
Input interface	DC12V electrical level signal, more than 10ms, or DC12V impulse signal driveling current, more 10mA				Dry contact with the pulse between 200ms~500ms
Transit speed	25~32 persons/min				30~45 persons/min
Working temperature	-25°C~55°C				-25°C~55°C
Working environment	Indoor / Outdoor (Shelter)				Indoor / Outdoor (Shelter)
Relative humidity	≤95%, no condensation				≤95%, no condensation
