KOC-09MT Multi-Channel Fiber
- Payment Type:
- L/C, T/T
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
| Place of Origin: | Guangdongshenzhen |
|---|---|
| Payment Type: | L/C, T/T |
Product Description
Product Description
Product Description
* KOC-09MT multi-channel fiber interferometer is multifunction automatic non-contact interferometer. It is developed for measuring the surface geometry of both single-fiber and multi-fiber connector. To replace the different fixtures, the user can do such as MTP/MPO, MT-RJ and SC/FC/ST/LC/MU connector endface 3D measuring on a same machine.
* KOC-09MT interferometer is using white light scan and red light phase-shifting two modes of measurement technique, which is able to reproduce the 3D shape of the connector and analyze the geometry parameter accurately.
Features
1. White light scan and red light phase-shifting, two modes of measuring method
2. One-click operation, automatic focus and measuring
3. High repeatability, high accuracy
4. Software calibration, no mechanical adjustment
5.3D-Mesh diagram and analysis chart directly to show the fiber and ferrule surface details
6. Test report and data will be saved in Excel format, easy for document management and print out
7. Shaking resistance
8. Cost efficient
Applications
1. SC/FC/ST/E2000, LC/MU/F3000 single fiber connector surface 3D geometry measuring
2. MTP/MPO, MT-RJ multi-fiber connector surface 3D geometry measuring
3. For 1~72 fibers connector endface 3D geometry measuring
4. Main measuring item: ROC, fiber height, core DIP, X/Y angle, roughness Ra/Rq
* KOC-09MT interferometer is using white light scan and red light phase-shifting two modes of measurement technique, which is able to reproduce the 3D shape of the connector and analyze the geometry parameter accurately.
Features
1. White light scan and red light phase-shifting, two modes of measuring method
2. One-click operation, automatic focus and measuring
3. High repeatability, high accuracy
4. Software calibration, no mechanical adjustment
5.3D-Mesh diagram and analysis chart directly to show the fiber and ferrule surface details
6. Test report and data will be saved in Excel format, easy for document management and print out
7. Shaking resistance
8. Cost efficient
Applications
1. SC/FC/ST/E2000, LC/MU/F3000 single fiber connector surface 3D geometry measuring
2. MTP/MPO, MT-RJ multi-fiber connector surface 3D geometry measuring
3. For 1~72 fibers connector endface 3D geometry measuring
4. Main measuring item: ROC, fiber height, core DIP, X/Y angle, roughness Ra/Rq
| Item | Spec. | Repeatability | Reproducibility |
| X/Y Radius of curvature (mm) | 3~ | 0.3% | 0.5% |
| X/Y Angle (°) | 0° or 8°/±0.5° | +/- 0.01 | +/- 0.02 |
| Flatness error(um) | Up to 16 | +/- 0.01 | +/- 0.02 |
| Fiber Height (nm) | Up to 3000 | +/- 15 | +/- 15 |
| Apex Offset (µm) | 0~200 | +/- 0.5 | +/- 1.5 |
| Measuring speed(Sec) | 1~2 fibers: 2 sec / 12 fibers: 10 sec | ||
| Focus speed(Sec) | 3 sec | ||
| Power | 24V DC | ||
| Weight | 5.5kg(Mainframe) | ||
| Dimension | L30*W12.5*H10(cm) | ||
