Freespace Isolator (103555-504)

Get Latest Price

Payment Type:: L/C, T/T

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Guangdongshenzhen
Payment Type:	L/C, T/T

Product Description

Features:
High Isolation & low insertion loss
Polarization Dependent
Compact size
RoHS 6/6 compliant

Application:
Optical Transmitter
Laser Diode Packaging

Parameter		Unit	P Grade	A Grade
Center Wavelength		nm	1310or1550 and CWDM
Isolation (at 23—C)	Min	dB	40	38
Insertion Loss ( at 23—C)	Max	dB	0.2	0.25
Clear Aperture		mm	Φ0.9 or other
Optical Power	Max	mW	300
Operating Temperature		ºC	minus 5 to 70
Storage Temperature		ºC	minus 40 to 85

Specifications (Standard) Dual stage

Parameter		Unit	P Grade	A Grade
Center Wavelength		nm	1310or1550 and CWDM
Isolation ( at 23—C)	Min	dB	60	55
Insertion Loss ( at 23—C)	Max	dB	0.4	0.5
Clear Aperture		mm	Φ0.9 or other
Optical Power	Max	mW	300
Operating Temperature		ºC	—5 to 70
Storage Tempe, rature		ºC	—40 to 85
