Autel MaxiScan jp701 Autel Code Reader Aisa Vehicle OBDII E

Autel Maxidiag JP701 Aisa Vehicle Code Reader
Autel Maxidiag JP701 supports all 9 tst modes of the latest J-1979 OBD2 test specifications. JP701 is designed for technicians to troubleshoot engine, transmission, ABS & airbag systems for major Japanese vehicles. Reliable, easy-to-use & affordable, the MaxiDiag JP701 is a time saver & a money maker.

Autel MaxiScan JP701 Vehicle Coverage

Toyota 1996 - 2008

Honda 1996 - 2008

Mazda 1996 - 2008

Nissan 1996 - 2008

Mitsubishi 1996 – 2008

Global OBD II compliant US, European & Asian vehicles.

Autel MaxiDiag JP701 Feature and Function

1. Retrieves generic { PO, P2, P3 & UO} and manufacturer specific (P1, P3 & U1 ) codes.

2. Supports all current OBD2 Protocols, including CAN (Controller Area Network).

3. Displays DTC definitions on-screen.

4. Views FREEZE FRAME Data.

5. Displays O2 Sensor Data as well as LIVE Datastream parameters.

6. Reads stores and play back of LIVE Sensor data.

7. Data Graphing, 1996 and newer.

8. Memory/ Battery backup for off vehicle data review and analysis.

9. Performs Modules Present test.

10. Retrieves Vehicle Information. {VIN, CID & CVN }.

11. Easy and reliable to use.

12. Built in DTC look-up Library.

13. Prints data via PC.

Autel MaxiDiag JP701 Specification

1. Display: Backlit, 128 x 64 pixel display with contrast adjustment.

2. Operating Temperature: 0 to 60°C (32 to 140 F°).

3. Storage Temperature: -20 to 70°C (-4 to 158 F°).

4. External Power: 6.0 to 21.0 V power provided via vehicle battery.

5. Internal Power: 6V power provided by four 1.5V batteries.

6. Length Width Height: 210 mm (8.27”) 99 mm (3.90”) 38 mm (1.50”)

7. NW: 1.0 kg (2.2lb), GW: 1.2 kg (2.65lb).

Package List:
1pc x JP701 Main unit
1pc x OBDII Cable
1pc x USB Cable
1pc x CD
1pc x User's Manual

1pc x Nylon Carry case
