Stainless steel Sauna Steam Generator Cuboid , 12kw 380V wi

ultra quiet steam generator auto drain down Mirror-polished stainless steel KSA-S120 steam generators 12.0kw/220v-230v or 400v/ 50~60Hz for steam bath

Quick Detail:

1. Super duty model
2. Controls sauna temperature
3. Temperature high limit switch
4. With cleaning and draining function
5. Power:12.0kW, voltage: 220/380V, phase:3
6. Two controllers: KSA-elegance
7. Operates machine for 1~60 minutes before turning off
8. Ultra quiet steam generator
9. Rapid steam function
10. Stainless steel constructions
11. Automatically shuts down when water level is too low

Power flush pressurized inner tank system is one of the host advantages of KSA-S steam generators. The other main functions are: pressure relief automatically, thermal overload safety cut out, self-diagnose message and steam fast response etc:

1. Control panel: Touch screen digital and optional
2. Type: Wet Steam Sauna
3. Power output: 12.0kw
4. voltage: 380~400V
5. phase: 3
6. Current: 18.2A
7. Main Material: stainless steel tank and Mirror-polished stainless steel shell
8. Color: stainless steel
9. Auto protection: over-heat protect, boil dry protect, pressure balancing valve, leakage protect, lack of water protect and the others
10. Auto function: auto water inlet , auto drain, auto flushing, auto power off
11. Shape: Cuboid
12. Size: 475*185*450mm
13. Room volume(cubic meter):11~14
14. Usage: steam sauna room
15. working time: 1~60 minutes or long time
16. Heating: heat elements
17. Power source: Electric
18. Time Setting: 1-60mins
19. Temperature range to control: 95 F degree~131 F degree
20. Temperature range to show on control panel: 43 F degree ~140 F degree

Stainless steel Sauna Steam Generator Cuboid , 12kw 380V with 3 phase

Description:

For Steam Spa’s, Showers, Baths, Shower cabins

Enjoy the elegant and professional steam generator designed to work in a residential or commercial environment.

The features of KSA-S120 12.0kw steam generator:

Heat element material: stainless steel 304, 6pcs 2.0kw

Shell material: Mirror-polished stainless steel shell 304

Water tank material: stainless steel 304

Power: 12.0kw

Room volume use: 11~14cubic meter volume

Recommend features: auto drain, auto turn on/ turn off, auto pressure relief, auto cut out when over heat, auto flashing etc

• Continuous steam output
• Super quiet operation
• Intelligent to indicate fault
• Have pause function
• Intelligent to save two sets of temperature, can individual set time by memory
• Light can be connected to illumine, water inflow to magnetize and filtrate etc.
• Intelligent to heat by segment, automatic to turn off and wash, with pressure to drain.

1 set steam generator contains:

1 unit KSA-S 12.0kw steam generator mirror-polished stainless steel shell with full sus body

1 unit KSA elegance touch screen control kit

1 unit mirror-polished stainless steel steam diffusers

1 unit power flush pressurized inner tank system

1 unit electronic thermostat

1pcs water proof control wire

The KSA-S steam generator is with new electronic touch screen control kit and new mirror-polished stainless steel 304# steam head. Full body made of stainless steel, durable and luxurious.

Sequential heating to save energy: Each KSA-S steam generator has 3 groups of heating elements to provide heating by segment. From cold all 3 groups operate for maximum power and rapid heating, when the steam room temperature is almost reached, then group 1 stop, when the required temperature is achieved, then group 2 stop. The group 3 alternates on and off to gently maintain the temperature without large fluctuations improving user comfort.

1. The KSA Elegance touch screen control kit has 6 bottoms to set working stages. Working time 1-60mins can be adjusted or long , the setting temperature of the steam will be in 6-60C degrees and can be adjusted between 35-55C degree (95-131F degree).KSA-S steam generators feature an advanced electronic control with fault diagnostics having different code to show each situation of the generators. Safety features include boil dry protection, over heating protect and power flush pressurized inner tank system.

2. KSA-S steam generators have an automatic drain down with a self flushing cycle to dump the boiler contents in a controlled manner. At the end of each steaming session the drain valve will open and after a short time the cold water inlet valve will open to give a period of continuous flushing and draining. Flushing and draining the boiler reduces the build up of damaging limescale, cooling the elements before the final drainage helps prolong their useful life.

Applications:

For 11~14m³ residential and commercial steam baths, Steam Spa’s, Showers, Baths, Shower cabins

A few minutes of steam daily, in the comfort of your own home, is an opportunity to improve your overall well-being in every way.

A daily steam bath is a remarkable way to indulge yourself.

It causes the perspiration that is the single healthiest thing you can do for your skin. Stress and negativity quickly dissipate in the soft clouds of intense yet comforting heat.

Specifications:

1. Black and White Touch screen control panel with Digital display
2. Control panel used the advanced inducing technology
3. Controls sauna temperature 35 degree to 55 degrees
4. Controls sauna time 1 minute to 60 minutes or long time
5. Intelligent to heat by segment
6. Intelligent to fill water with steam
7. Intelligent to do a self flushing cycle
8. Light can be connected to controller
9. Intelligent to indicate fault with the code
10. Can pause at working
11. To show CH can working for long
12. Intelligent to save two sets of temperature, can individual set time by memory
13. Automatically shuts down when water level is too low
14. Temperature high limit switch
15. Waterproof grade: IPX5
16. Auto protection: over-heat protect, boil dry protect, pressure balancing valve, leakage protect, lack of water protect and the others
17. Auto function: auto water inlet , auto drain, auto flushing, auto power off
18. We will provide some spare parts to our customer as replacement.

• Durable metal construction
• Superior heating elements – improved energy efficiency
• Waterproofed link cable for control panel(s)
• Intelligent touch screen control kit
• Electronic thermostat
• Ultra quiet steam generator
• Rapid steam function
• Full stainless steel constructions
• Steam diffuser in chrome allowing essential oils into the steam
• Timer control, automatically switches off after setting time
• Mirror-polished stainless steel shell
• More than 10 year manufacturer experience!

Parameters:

We normally produce KSA-S 3.0kw, KSA-S 4.0kw, KSA-S4.5kw, KSA-S 5.0kw, KSA-S 6.0kw, KSA-S 7.0kw, KSA-7.5kw, KSA-S 8.0kw, KSA-S 9.0kw, KSA-10.5kw, KSA-S 12.0kw, KSA-S 15.0kw, KSA-S 18.0kw, KSA-S 22.0kw, KSA-S 24.0kw in stock.

KSA-S120

Competitive Advantage:

Every KSA-S steam generator is subjected to 6 strictly controlled tests by Shenzhen TOLO Leisure Equipment:
1. 48 hour continual test for circuit board
2. Controller is tested for all functions
3. High voltage test
4. Earthing resistance test
5. Power test.
6. Operational test of every steam generator before packing

• Intelligent touch screen control kit
• Fast start of steam in second, not minute
• Power flush pressurized inner tank system
• Full stainless steel constructions
• Mirror-polished stainless steel shell
• More than 10 year manufacturer experience!
