PAL / NTSC / SECAM Industrial LCD Displays
- Min. Order:
- 1
- Min. Order:
- 1
- Delivery Time:
- 30 Days
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | CHINA |
|---|
- 1920×1080 resolution
- AC 100V~240V voltage
- Professional appearance design,delicate and generous.
- Powerful cooling design,stable performance,long life span.
- Full metal shielding structure,can profit the external electromagnetic interruption,no radiation.
PAL / NTSC / SECAM Industrial LCD Displays with 600cd/㎡ Brightness
Description:
- Ultra-slim design,convenient use,delicate appearance.
- Industrial A+ grade LCD panel
- High contrast,High brightness,vivid image layout,bets details performance.
- Auto eliminate blur function,long life span.
- Auto adjust VGA image reproduction rate.
- Multiple date-image adjustment circuit,low image distortion.
- Intelligence temperature control fan design,green and quiet.
- Wide visual angle 178°,aspect ratio 4:3
- Rich signal input,output interfaces,adapted in the different environments.
- Appling the latest 3D digital image decode chipset,the latest DNR,image clear,clean and vivid.
- Intensive the IR receiver,support the IR remote to modify the monitor parameters.
- Build-in stable power,low consumption,long life span>60000hours
Applications:
Stock exchanges, Traffic control centers, Airports, media centers, military systems, public space, shopping areas, banks, schools, hospitals, special circumstances etc.
Specifications:
Technical Parameter for LCD Panel
|
product |
42" HD LCD Monitor |
|
model |
MJHD-420 |
|
Screen type |
42" TFT LCD |
|
Display area |
930(W)×528(H) |
|
Aspect ratio |
16:9 |
|
resolution |
1920×1080 |
|
Number of colors |
16.7M |
|
Dot pitch |
0.484(H)×0.484(V) |
|
brightness |
600cd/㎡ |
|
contrast |
4000:1 |
|
Viewing angle |
178°/178° |
|
Response time |
5ms |
|
HF |
31k~60kHZ |
|
VF |
56~75HZ |
|
color system |
PAL/NTSC/SECAM |
|
Signal interface |
Input:2*BNC,1*VGA,,1*HDMI,1*AUDIO output:1*BNC |
|
voltage |
AC 100V~240V |
|
On mode |
≤220W |
|
Standby model |
≤3W |
|
Working temperature |
0°~50° |
|
humidity |
20%~80% |
|
Life |
60000H |
|
color |
Black/white/customized |
|
installment |
Desktop/wall mounted |
|
certification |
CE/3C/FCC/UL |
|
Dimension |
996.6×596×116.2 |
|
Net weight |
37KG |
Competitive Advantage:
Wide voltage range,AC 110V~240V,industrial grade design,can be used in harsh environment.
