122*32A COB Graphic Monochrome LCD Module for Security system
Description:
1. IC Connection Method: COB
2. Viewing Direction: STN Yellow-Green/Blue Negative
3. Viewing Direction: 6 O'Clock
4. Backlight type & Color: LED, White/Yellow-Green
5. Driving Method: Duty 1/32 Bias 1/6
6. Control/Drive IC: PT6520-H(D)
7. LCD Connection: Zebra
8. MCU Interface Type: 8Bit Parallel mode
9. Main Component: LCD+Controller+PCB+BL+Zebra
Main Application
|
Wire tester |
Communications equipment |
|
Instrument & meter |
Car audio-visual |
|
Industrial equipment |
Home appliances |
|
Manipulator controller |
Consumption electronics |
|
Medical Equipment |
POS |
|
Electricity,Power Controller Device |
Beauty Equipment, |
|
Semi auto analyzer |
Medical Equipment |
|
ECG |
Injection Machine |
Essential Specification
|
COB TSC-G12232A Series |
|
|
Parameter |
Data |
|
Viewing Angle |
6’O CLOCK |
|
V.A. |
60.5*18 |
|
Dots |
122*32 |
|
Driving IC |
PT6520-H(D) |
|
Operation Voltage |
-18℃-+70℃ |
|
Storage Voltage |
-30℃-+80℃ |
|
Interface timing |
8-bit Parallel |
|
Connector |
ZEBER |
|
Driving Condition |
Duty 1/32 Bias 1/6 |
The main model of 122*32A Series is as follows
|
