3 in 1 Indoor P7.62 Advertising Display for Shopping Mall 1

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China

Product Description

3 in 1 Indoor Advertising Display for Shopping Mall 17222 (dot/m2) 244 x 122 (mm*mm) P7.62

Description:

P7.62 indoor LED billboard uses SMD3528 LEDs, SMD3528 is one kind of mature SMD series LEDs, it has been proved

very stable performance, and high cost efficiency.

We provide die-casting cabinets and aluminum cabinets for customers options, both of them are very lighter weight.

Noiseless ventilation system and power supply system bring audiences prefect visual and auditory satisfaction.

Fast locks and hang up poles make the installation and dismantling easy job. Also we use flight cases for packing of

cabinets and accessories which enable customers to move the LED wall anywhere conveniently.

Specifications:

Catalog	UC-IF-P7.62S
LED encapsulation	3 in 1
LED lamp type	white/black optional
Pixel pitch	7.62
Module size	244 x 122 (mm *mm)
Module resolution	32 x 16
Cabinet type	common cabinet
Pixel configuration	1R1G1B
Pixel density	17222 (dot/m2)
Best viewing angle	H: 140° V: 140°
Max.power consumption	1000W/m2
Frame change frequency	60Hz/s
Refresh rate	180Hz~1600Hz
Luminance	2200cd/ m2 (1/4)
Driving mode	1/4 Scan constant current
Working voltage	AC 220V/ 50Hz or 100V / 50Hz
Working environment	Temperature: -10℃ ~ 50℃, Related humidity: 10% ~ 90%
Grey scale / color	8192 grades for R, G and B, Display ≥549 billion colors (synchronized)
Brightness adjustment	(Manual adjustment: 1024 levels) (Automatic adjustment: 8 grades)
Control system	Synchronous / off-line control system; Network Cable or optical fiber transmission
MTBF	10000 hours
Life-span	50000 hours
