ODM Diesel Engine Cleaning Machine Electric Ultrasonic Cleaner
Quick Detail:
1. Name: Industrial Supersonic Cleaning machine
2. Custom made for air filter panel cleaning
3. Model: KBG-10144
4. Material:Stainless Steel
5. Power: 7200W
6. Interior tank size: 1750*700*600mm
7. Ultrasonic power adjustable
8. Frequency: 28KHz (or As request)
9. Cleaning medium: Environmentally friendly water-based cleaning agent
10. With CE certification
11. OEM & ODM
Description:
KBG-10144 Industrial Ultrasonic cleaning machine designed with Ultrasonic power 7200W, Frequency 28KHz or as request, interior tank size with 1750x 700x 600(L x W x H mm ), heating power 24KW, with external stainless steel heating plate, maintenance more convenient. Generator for digital type, power adjustable, and Ultrasonic current, ultrasonic power, frequency, cleaning time are all be realization of digital display and setting. The machine power, frequency, and size can be designed according to your requirements.
This custom made Single tank Industrial Ultrasound cleaner using Environmentally friendly water-based cleaning agent . Ultrasonic cleaning tank Main tank made of high quality SUS304 2.0mm stainless steel production; the side which match transducers use of high quality SUS316L 2.0mm or SUS304 2.5mm stainless steel. Digital Ultrasonic generator, single chip microcomputer technology, more stable operating conditions, the output power is more powerful. This series Industrial Ultrasonic cleaning machines are suitable for electroplating treatment and cleaning after plating; car accessories cleaning; metal components cleaning; machine parts cleaning; optical frames cleaning, etc.
We design the Industrial Ultrasound cleaners with features:
A. Imported stainless steel plate and components, full stainless steel structure, good appearance and durable.
B. Cleaning tank equipped with heating and temperature control device, temperature control adjustable 30~110℃
C. Imported transducer with high quality, strong output for ultrasonic power.
D. Cleaning tanks and generators designed to be separated, easy to using and maintenance.
E. New circuit of generator with single chip computer driven, ultrasonic power adjustable, ultrasonic cleaning time adjustable, frequency display, over current and over loaded function make the generator more secure.
F. Ultrasonic vibrations with bottom vibration and side vibration, respectively two ways for different cleaning requirements.
G. Industrial Ultrasonic cleaners can be made according to customers requirements
Applications:
Industrial Ultrasound cleaning machine are suitable for cleaning with car accessories; metal components; machine parts; optical frames, metal parts, electroplating accessories, watch and clock accessories, metal accessories, terylene filter core, semiconductor silicon, tools, lens, spectacle frames, jewelry and glass containers... etc
Specifications:
|
No. |
System |
Main Parts |
The main parameters and performance description |
|
1 |
Machine shelf |
Machine size (about) |
1920X870X750MM |
|
Machine shelf |
Outer door panel with genuine Pohang SUS304 # stainless steel plate 0.8mm |
||
|
Material |
Outer frame 40 x 40 mm stainless steel square pass, the whole chassis used channel steel production |
||
|
2 |
Interior tank size |
Dimension |
1750 × 700 ×600 mm ( L×W×H) |
|
Material |
Genuine Pohang SUS304 # δ2 mm stainless steel plate |
||
|
4 |
Ultra sonic system |
Transducer |
High Q value transducer, 28KHZ; 7200W=144 PCs × 50W / pc |
|
Ultrasonic generator |
4 sets |
||
|
5 |
Heating system |
Heating plate |
Taiwan "Paul Long" stainless steel heating plate Total heating power: 24KW (24PcX 1KW/Pc) |
|
Temperature |
The machine heating systems using the liquid temperature from room temperature to 100℃ arbitrary adjustable |
||
|
Temperature sensing |
The probe is inserted in the cleaning tank wall, to ensure accurate temperature measurement |
||
|
Insulation Design |
For efficient energy consumption of the (electrical), reducing the operating costs of the cleaning work, corresponding to the cleaning tank, affixed in the groove outer wall insulation cotton insulation protection (limited thread portion) |
Competitive Advantage:
1. Our factory Machines produced with good quality parts, and competitive price. Machine warranty is for One year, for all the machines itself quality problems which in normal use and under warranty, we’ll provide maintenance and provide machine parts free of charge.
2. For all our machines before delivery had passed Ke-beige Limited strict inspection, at least be testing 24-48 hours before delivery.
3. Provide ODM and OEM, Customers only need to told us the products which request for cleaning, and their detailed cleaning requirements, our engineers will provide them perfect solution free of charge. Also, clients own machine design and requirements all be OK.
4. After-sale service: To make sure our high quality and top service from us, before order will send the machine design drawing and specifications to clients for confirmation, before machine delivery we’ll testing the machines 24-48 hours and QC fully inspection, if there is any problem in Customer’s place, we’ll helping to checking out the problem and provide the machine parts for replace free of charge, if can’t to solve please return to us for a new one replace.
