New Design Emergency LED T8 Tubes

Description:
L05G-I33V emergency LED T8 tubes
has two functions of general lighting and emergency lighting.
When suddenly an earthquake or other natural disasters coming,
the city power would be crushed down. The emergency LED tubes
can provide 3-5 hours lighting with their own battery,
winning the time for saving.
It also can work as common light when the city power is working well.

Advantage:
●Tube with external power supply
●With rechargeable battery
●Lockable rotating end caps (patent)
●Warranty: 3 years for tube
            2 years for power supply
            1 year for battery
●Plastic end caps ensure to pass 4000V HI-POT test
●Certificate: CE, ROHS
●Emergency time: 3-5 hrs

Feature:
(A）Power:
1. Size: 430x40x30mm
2. Input voltage: AC100V-240V
3. Frequency: 60Hz to 50Hz
4. Output power: 9W Max output power: 22W
5. Emergency output voltage: 33V DC
6. Battery capacity: 11.1V 2000mA/h
7. Weight: 620g
8.PF: 0.85
9. Power Efficiency: >0.92
10.Emergency time: 3-5hrs

(B) Tube
◆Light Source: SMD3528/3020 LED，
◆ Material: AL + Strengthen PC cover
◆Lifespan: >50,000hrs
◆Up to 70% Energy Saving Consumption
◆High Brightness
◆Easy Installation
◆Extended Life
◆Ballast Bypassed/ Removed
◆Instant On
◆High Shock/Vibration Resistance
◆Environmental-friendly: Without hydrargyrum or other harmful materials listed in RoHS.
◆No Buzzing
◆No Radio Frequency Interference
◆No Flickering
◆Fast Return on Investment

Technical Specifications:
1. Electrical Specifications:

Model	Power	Dimension (mm)	LED Quantity  (pcs)	Luminous (Frosted lens)	Luminous (Clear Lens)
L05G-I33V	9W	26x588(2FT)	110	1000±10%	5±10%
L05G-I33V	18W	26x1198(4FT)	210	1800lm±10%	2100lm±10%
L05G-I33V	22W	26x1498(5FT)	240	2200lm±10%	2400lm±10%

Operation Temperature:	-20°C to 40°C
Working humidity:	96%
Voltage:	110V-220V
Frequency:	60HZ-50HZ
Power Factor:	>0.92
Power supply Efficiency:	0.86


2. Photometric Specifications:

LED Luminous Efficiency:	Up to 100lm/w
CRL:	Ra: >70
CCT:	Warm White 3000k
daylight white 4000k
pure white 5500k
cold white 6500k

3. Mechanical Specifications:
◆Beam Angle: 120°
◆Light-emitting surface: 230°
◆Frosted or clear cover available on request
◆Weight: 588MM/156.8g, 1198mm/318g, 1498mm/393g, power supply/635g
◆Can be placed in conventional T8 or T10 fluorescent brackets and replace fluorescent tubes

Applications (Civilian Using & Commercial Using)
Offices, Hotels,   Factories,   Shopping Malls,   Hospitals
Residential/institution buildings
Schools, colleges, and universities
Rail Stations & Airports
