P10 1m diameter ball LED display
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
Product Description
Product Description
Basic Specification
| Voltage | 220V |
|---|
Detail Description
P10 1m diameter ball LED display
| Item | PH10 ball led display technical parameters | |
| Basic parameter | LED | SMD3528 |
| Pixel pitch | 10mm | |
| Pixel composition | 1R1G1B | |
| Basic color | Red (Wave length 620-630nm) Green (Wave length 520-530nm) Blue (Wave length 465-475nm) |
|
| Pixel density | 10,000dots/m² | |
| Blind dots | ≤3/10,000 | |
| Module split joint seam | ≤0.1mm | |
| Best viewing distance | 10-60m | |
| Viewing angle | Horizontal 160°, Vertical 160° | |
| Surface flatness | ≤0.1mm | |
| Uniformity | Uniform brightness,uniformity 1 : 1.3 | |
| Circuit board layout | Reasonable layout, circuit standard and aesthetic | |
| Working temperature | —20°～50° | |
| Humidity | 25°～95° | |
| Electricity | Input voltage (AC) | 220V, ±10% |
| Linkage current | < 3mA | |
| Input frequency | 50/60HZ | |
| Input rated power | <375W/m² | |
| Input max. power | <750 W/m² | |
| Control system | Host operating system | XP computer+control software and hardware+playing software and hardware |
| Control way | Synchronous with computer VGA(display) | |
| Control system | DVI display card + full color control card + optical fibre | |
| Input way | Computer and ancillary, PAL/NTSC/SECAM, S-Video; VGA; RGB; Composite Video; SDI, etc. | |
| Main technical parameters | LED drive | 1/8 scan Constant current |
| Computer display mode | 640×480, 800×600, 1024×768 | |
| Refresh frequency | ≥800hz | |
| Grey grade | 4096 grade | |
| Brightness | ≥1500cd/m² | |
| Life span | 100000 hours | |
| Display content | Video DVD, VCD, TV, Image, Text, Animation and others | |
| Continuous failure-free working time | ≥10,000hours | |
| Interface | Standard Ethernet network | |
| Communication media, control distance | Multimode optical fibre<500m, single mode fibre < 30km, cat 5 cable < 100m | |
| Protection | Damp proof, dust proof, anti-corrosion, static free, anti-thunder, with over current, short circuit, over voltage and short voltage function | |
| Software | Apexls video playing software |
Additional Information
| Payment Terms | T/T |
|---|---|
| Minimum Order | 5 |
| Lead Time / Delivery Time | 30 Day(s) |
| Sample Available | NO |
| Delivery Details | FOB Shenzhen |
| FOB Port | Shenzhen |
| Loading Info | by sea or by air |
| Packing Info | flight case |
| Target Market(s) | Africa(except Middle East), Eastern Europe, Hong Kong/ Macao/ Taiwan, Japan & Korea, Latin America, Mainland China, Middle East, North America, Northern Europe, Oceania, Central & Southern Asia, Southeast Asia, Western & Southern Europe |
