P6 Full Color Taxi Top LED Adertising Display

P6 Full Color Taxi Top LED Display

Specification

1. 7 inch & 9 inch(16: 9)digital LCD, Wide Viewing Angle, High Brightness;

2. Windows CE 5.0 operating system;

3. B/S framework for server manege-ment platform, easy to remote manege-ment, monitor;

4. File updating: Use WiFi or 3G remote wireless network to update terminal advertising program via back-stage management software;

5. Users can set up the startup picture and screen saver picture according to their demand;

6. Via back-stage management software, remotely set up auto turn and off, online upgrade, multiple templates, playlist, checking statistical form;

7. Support SD card with anti-theft lock in Bayonet socket position;

8. Support autocycle play, image, video, music mixed playing, screen splitting, and one video zone, zone, more scrolling caption;

9. Audio output: Stereo horn(1W*2), sweet and relaxing sounding;

10. Support file layout MPEG1, MPEG2, MPEG4, WMV9, BMP, JPG, JPEG, PNG, MOV, FLV, etc.

11. With human infrared induction function.

12. Simple installation, do not need to change the back cushion.

13. Headrest adjustable pipe diameter: 10-12mm Headrest adjustable tube pitch: 130-180mm

14. Color: Black, Gray, Cream-colored

P6 Full Color Taxi Top LED Display Parameters

Pixel pitch: 6mm

Module size: 192mm×96mm

Module density: 40,000dots/sqm

Pixel configuration: RGB ( SMD 3 in 1 )

Red wavelength: 625±2nm

Green wavelength: 525±2nm

Blue wavelength: 470±2nm

Best viewing distance: more than 5 m

Horizontal viewing angle: 140°

Vertical viewing angle: 70°

Maximum power consumption: ≤1200W/m2

Brightness: ≥5000cd/m2

Gray scale: 16bits of per color

Color temperature: 6500K

Control method: Asynchronization byUSB/3G/Wifi

Driving method: 1/8 scanning

Frame frequency: 60Hz

Refresh frequency: ≥300 Hz
