USB 3.0 Micro B Type, Male Soldering Wire Type

USB 3.0 Micro B Type, Male Soldering Wire Type
P/N:HT U3 B M2 Q 02 X X X X X

Features & Benefits
Fully compliant with USB2.0 & 3.0 specification.
Provides the interface for Super Speed up to 5 Gbps data rate.
2 metal Friction lock grounding fingers and Polarization plastic  design ensure plug retention.
Rugged Gold-plated leaf contact withstand up to 5000 cycles.
High temperature plastic for SMT process and Halogen Free solution.
Two Board Lock hold-down  ensure mounting Force.
Full metal shielding for EMI / RFI / ESD protection.

Electrical
Voltage Rating: 30 V AC
Current: Pin 1 & Pin 4 -- 1.8A
Other Pins -- 0.25A min.
Contact Resistance:
30mO Max (Pin 1 & Pin 4)
50mO Max (Other Pins)
Dielectric Strength:100 V AC
Insulation Resistance:100MO min

Mechanical
Insertion Force: 35 N max.
Extraction Force: 10 N min.
And After Test 8 N min.
Standard Durability class: 1500 cycles
High Durability class: 5000 cycles

Environmental
Operating Temperature: 0 celsius degree ~+ 60 celsius degree
Storage Temperature: -20 celsius degree~+ 85 celsius degree

(6) CONTACT FINISH
A: Selectively G.F. over 50uin Ni;
B: Selectively AU 3uin over 50uin Ni;
C: Selectively AU 5uin over 50uin Ni;
D: Selectively AU 10uin over 50uin Ni;
E: Selectively AU 15uin over 50uin Ni;
F: Selectively AU 30uin over 50uin Ni;
(7) Shell Plating
1:Gold-Plated
2:Nickel-Plated
3:Tin-Plated
(8) Insulator Material
1: NYLON
2: LCP
3: PBT
(9) Insulator Color
1: Black
2: White
3: Blue
(10) Environment
R: RoHS
H: Halogen Free
