Mini DisplayPort to VGA Adapter

Mini DisplayPort to VGA adapter

This Mini DisplayPort to VGA adapter has many features that enable it to perform in a superior manner. Among those features you will find:
● Mini DisplayPort 1.1a compliant receiver offering 5.4 Gbps bandwidth over 2 lanes
● Integrated triple 10-bit, 162 MHz video DAC for analog VGA signal output
● Supports up to 1080p, 1920 x 1200 reduced blanking video resolution
● EDID pass-through from PC source to display
● Spread Spectrum (de-spreading) for EMI reduction
● Automatic sink detection
● Low power standby mode operation initiated based on sink detection status
● Powered from Mini DisplayPort source
● 3.3V IO, 1.2V Core
● Low power operation – Active 400mW, standby mode 15mW

Note: For few display cards, the image would not appear until the PC enters into Windows from DOS at the time of restarting.
