t5 led tube lamp 12W CE ROHS approved
  • t5 led tube lamp 12W CE ROHS approved
  • t5 led tube lamp 12W CE ROHS approved
  • t5 led tube lamp 12W CE ROHS approved
  • t5 led tube lamp 12W CE ROHS approved
t5 led tube lamp 12W CE ROHS approved
t5 led tube lamp 12W CE ROHS approved
t5 led tube lamp 12W CE ROHS approved
t5 led tube lamp 12W CE ROHS approved

t5 led tube lamp 12W CE ROHS approved

Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Product Description
Product Description
  • Product Details

Basic Specification

Luminous Flux: 1100±5%lumens
Efficiency: >80%
CRI: Ra>80
Power Factor: >0.9
Working Ambient Temperature: -30 ℃—+40 ℃
Material Aluminum, PC
Application Airport, Church, Cinema, Gallery, Garage, Hospital, Hotel, Meeting Room, Museum, Office, Restaurant, School, Shopping Mall, Sitting Room
Voltage 90-260V
Light Source LED

Detail Description

t5 led tube lamp

Paramaters:


Power Consumption: 12W
Input Voltage: AC 100-240V±20 V
Luminous Flux Output: 1100lm±5%
Power factor: >0.9
Color Index 80 Ra
Beam Angle 120 Degrees
Light Source: SMD LED
Housing material Aluminium + PC Cover
Lifespan time 50000 Hrs
Demension Ф15.8mm*L848mm ±1mm
Working Temperature: -30 —+40
Carton size 900x190x170mm   30pcs/Carton
Gross weight 10.5kg/carton


All models of of T5 tube:


Model No. Power Voltage Dimmension Lumens PC Cover
TOP-T5-600-6W 6W AC85-265V D15.8mm*548mm 550±5%Lm Clear / Milky
TOP-T5-900-8W 8W AC85-265V D15.8mm*848mm 750±5%Lm Clear / Milky
TOP-T5-1200-12W 12W AC85-265V D15.8mm*1148mm 1100±5%Lm Clear / Milky
TOP-T5.7-600-8W 8W AC85-265V D22mm*548mm 750±5%Lm Clear / Milky
TOP-T5.7-1200-16W 216W AC85-265V D22mm*1148mm 1500±5%Lm Clear / Milky
TOP-T8-1500-23W 23W AC85-265V D22mm*1448mm 2200±5%Lm Clear / Milky










Product Features:
  1. Made by high Brightness SMD LED
  2.  High-efficiency constant current driver, No strobe flash ;Instant start,eyes protection
  3. Excellent aluminum heat dissipation body, securing long life span of LED.
  4. Energy saving:Saving up to 85% energy comparing to incandescent bulbs, and 50%,comparing to fluorescent tubes
  5. Environmental protection:No heavy metal and No air pollution, materials can be  recyclable;
  6. NO UV & IR radiation;
  7. Suitable to a wide range of temperatures;
  8. Light Decay:retain 75% brightness after working 35000 hours;
  9. Life span 50000 hours, 50 times compared with incandescent bulb.

Application:

  1. Replacement of fluorescent tubes;(removal of ballast);
  2. Hotel, restaurant, home, commercial lighting, industrial lighting;
  3. Advertisement lighting ;
  4. Automobile, train, ship and other transportation lighting.

Caution:

  1. Please check the voltage of power before use;
  2. Properly packing, avoid pressing during transportation;
  3. Use dryer during storage, storage temperature≦60%;
  4. Only suitable for indoor lighting。


Warranty:

  1. Warranty: 3 years .
  2. Improper operation in storage installation, operation and maintenance would be beyond guarantee.
  3. Specifications are subject to the supplier\'s modifications without notice.





Production Line:








Honors and Certificates:





Factory Profile:





Additional Information

Payment Terms L/C, T/T, Others
Minimum Order 10PCS
Lead Time / Delivery Time 10 Day(s)
Sample Available YES
Delivery Details about 3-15 working days after receiving payment
FOB Port Shenzhen
Loading Info Mainly we can ship the parts by DHL,FEDEX,UPS,TNT ect when the quantity is small. We can also ship by appointed cargo company by customers.
Packing Info Inner box + carton box; OEM for customer is also available
Target Market(s) Africa(except Middle East), Eastern Europe, Hong Kong/ Macao/ Taiwan, Japan & Korea, Latin America, Mainland China, Middle East, North America, Northern Europe, Oceania, Central & Southern Asia, Southeast Asia, Western & Southern Europe
