Basic Specification
| Weight | 70g(tube),210g (total) |
|---|---|
| Power | 8.5W |
| Life | 50,000 hours |
| Package | Yes |
| Color Tones | Warm Color |
| Lamp Base | G5 |
| Tube Diameter | T5 |
| Length | 60cm |
| Illuminant | LEDs |
| Light Source Chip | CREE |
| Voltage | 220V |
Detail Description
We are top 20 LED manufacturer in China, professional in LED Tube,T8 LED Tube , LED panel , LED Spotlight,LED ceiling light and LED bulb. Providing unique design super quality LED lights. All our LED lights have pass CE RoHS FCC approval.
7W T5 LED Tube (600mm)
Specifications
Module
ZRG-T5-600-GSP9-A1 (transparent PC cover)
ZRG-T5-600-GTP9-A1 (stripe PC cover)
ZRG-T5-600-GDP9-A1 (frosted PC cover)
Specifications:
| Total power consumption | 8.5W |
| LED consumption | 7W |
| Input voltage | AC90-250V, 50/60Hz |
| Power supply | built-in constant current |
| Lighting source | low power 3528/3014/5050 LEDs |
| LED quantity | 120pcs |
| Dimension | Φ16mm*600mm |
| Material | aluminum PCB and housing & PC cover |
| Lamp holder | G5 |
| Luminous flux | 700lm±10% |
| Luminous efficiency | 70–80lm/W |
| Color temperature | 2700-4500K,4500-6000K,6000-9000K |
| Viewing angle | ≤120 ° |
| CRI | more than 70 |
| Working temperature | -20~40°C(-4~104 °F) |
| Working environment | indoor use |
| Environment humidity | <90 percent |
| Protection rating | IP44 |
| Life-span | 50,000 hours |
| Weight | 70g(tube),210g (total) |
| Certification | CE, RoHS and UL pending |
| Warranty | 2 years |
Features:
1. The 7W T5 LED Tube (600mm) has high quality light source. The attenuation of SMD LED light source is less than 3% by 3000hrs aging test under temperature 50 degrees celsius, high luminous efficiency of single LED.2 Long life-span: 50,000hrs, 6 times longer than traditional 600mm T5 LED tubes.
3.600mm 7W T5 LED tube lighting is easy to install. Cut cost by reducing re-lamp frequency, especially in difficult to reach area that requires lift.
Applications:
7W 600mm T5 LED Tube can be extensively applied to general lighting, such as mall, store, hotel, office, supermarket, commercial building, station, bus, warehouse, signage, residential, parking lot, home, restaurant , train, railway, subway station, bank, warehouse, exhibition gallery, library, closet, factory, cabinet, cupboard, kitchen, refrigeration units etc. Replace conventional fluorescent lamp or sodium lamp. Energy efficient, environmentally friendly.
600mm 7W T5 LED TUBE Dimension
7W 600mm LED TUBE Eelectric Connection Diagram
7W 600mm LED T5 tube light Installation
1 ) Fitting with starter, inductive (magnetic) 7W T5 LED tube lighting
A.Remove the starter from the fitting
B. Plug the T5 LED tube into the fitting directly, it would be better to remove both starter and ballast
2) Fitting with electrical ballast
A.Remove the electrical ballast from the fitting
B. Connect the anode & cathode directly
C. Plug the 7W T5 LED tube 600mm into the fitting
1 ) Fitting with starter, inductive (magnetic) 7W T5 LED tube lighting
A.Remove the starter from the fitting
B. Plug the T5 LED tube into the fitting directly, it would be better to remove both starter and ballast
2) Fitting with electrical ballast
A.Remove the electrical ballast from the fitting
B. Connect the anode & cathode directly
C. Plug the 7W T5 LED tube 600mm into the fitting
7W T5 LED TUBE Test Report
600mm 7W T5 LED TUBE Dimension
600mm 7W T5 LED tube Frosted PC Cover
