Basic Specification
| Certification | CE, RoHS and FCC |
|---|---|
| Life | 50,000 hours |
| Package | Yes |
| Tube Diameter | T8 |
| Lamp Base | E27 |
| Color Tones | Warm Color |
| Power | 22W |
| Length | 60cm |
| Illuminant | LEDs |
| Light Source Chip | CREE |
| Voltage | 220V |
Detail Description
Our LED tube advantages:
1. Brand name of LED tube
2. Upper LED quality
3. Prompt shipment
4. Volume production facility
5. 85% exported with USD30 Million annual sale.
Explosion-proof T8 LED Tube Light
Specifications
Module
ESD-ZRG-2SFT8-0600 (2FT)
| Total power | 22W |
| Input voltage | AC90-250V, 50/60Hz |
| Power supply | internal constant current |
| Lighting source | low power 3528/3014/5050 LEDs |
| LED quantity | 288(2*144pcs) |
| Dimension | 675mm*166mm*100mm |
| Material | aluminum PCB and housing & PC cover |
| Luminous flux | 1440lm±10% |
| Luminous efficiency | 75–85lm/W |
| Color temperature | 2700-4500K,4500-6000K,6000-9000K |
| Viewing angle | ≤120 ° |
| CRI | more than 70 |
| Working temperature | -20~40°C(-4~104 °F) |
| Environment humidity | <95 percent |
| Working environment | indoor use |
| Protection rating | IP44 |
| Life-span | 50,000 hours |
| Certification | CE, RoHS and FCC |
| Warranty | 2 years |
Features:
The light can work safely in explosive and flammable environments. Full plastic explosion-proof fluorescent lamps comprise bodies manufactured in glass fiber reinforced polyester and transparent parts manufactured in polycarbonate. They have good protection ability from various chemical matters in factories because of high stability and mechanical strength. The material this lamp used can prevent from being corroded effectively.
Applications:
1 Explosion-proof, corrosion-proof and dust-proof.2 High quality light source. The attenuation of SMD LED light source is less than 3% by 3000hrs aging test under temperature 50 degrees celsius, high luminous efficiency of single LED.
3 Advanced constant current driver with short circuit protection, open circuit protection, overload protection, etc.
Explosion-proof T8 LED Tube Eelectric Connection
600mm Explosion-proof T8 LED Tube Light Installation
1 Before installation, check whether the power is suitable. The tube must work under the right voltage according to the specification.
2 Cut off the power first for safety
3 Don’t take the tube apart
4 Recommend indoor use
5 Please use it in a ventilation environment and keep it from water.
6 DO NOT connect power (positive & negative) to the two pins at one end only. If they are connected together (positive/negative), you will create a short circuit!
1 Before installation, check whether the power is suitable. The tube must work under the right voltage according to the specification.
2 Cut off the power first for safety
3 Don’t take the tube apart
4 Recommend indoor use
5 Please use it in a ventilation environment and keep it from water.
6 DO NOT connect power (positive & negative) to the two pins at one end only. If they are connected together (positive/negative), you will create a short circuit!
600mm Explosion-proof T8 LED Tube Test Report
600mm Explosion-proof T8 LED Tube Spectrum Test Report
600mm Explosion-proof T8 LED Tube Installation
