Factory Best Price 900mm Mini Bracket T5 LED Tube
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
Product Description
Product Description
Basic Specification
| Certification | CE, RoHS and FCC |
|---|---|
| Warranty | 2 years |
| Life | 50,000 hrs |
| Color Tones | Warm Color |
| Voltage | 220V |
| Dimmable | Yes |
| Lamp Holder | E27 |
| Power Storage or Not | Yes |
| Illuminant | LEDs |
| Light Source Chip | CREE |
| Package | Yes |
| Power | 14W |
Detail Description
We are top 20 LED manufacturer in China, professional in LED Tube,T8 LED Tube , LED panel , LED Spotlight,LED ceiling light and LED bulb. Providing unique design super quality LED lights. All our LED lights have pass CE RoHS FCC approval.
Specifications:
| Total power | 14W |
| LED consumption | 11W |
| Input voltage | AC90-250V, 50/60Hz |
| Driver output | 35-42VDC/380-400mA |
| Tube input | 40VDC/380-400mA |
| Power supply | internal constant current |
| Lighting source | low power 3528/3014/5050 LEDs |
| LED quantity: | 180pcs |
| Dimension | 28mmx25mmx870mm |
| Material | aluminum PCB and housing & PC cover |
| Luminous flux | 1100lm±10% (frosted) |
| Luminous efficiency | 75–85lm/W |
| Color temperature | 3000-3500K, 4500-6500 K, 6500-9000K |
| Viewing angle | ≤120 ° |
| Working temperature | -20~40°C(-4~104 ° F) |
| Working environment | indoor use |
| Life-span | 50,000 hrs |
| Weight | 300g (net) |
| Certification | CE, RoHS and FCC |
| Warranty | 2 years |
Module
ZRG-T5-0900-GSP11-E1 (transparent PC cover)
ZRG-T5-0900-GTP11-E1 (stripe PC cover)
ZRG-T5-0900-GDP11-E1 (frosted PC cover)
Features:
1 No need for starter and EM ballast, direct live voltage input2 Toxic-free materials-does not contain glass, lead or mercury
3 Vibration proof and retains stable performance in tough environment
4 Can be directly placed in conventional T4 or T5 fluorescent brackets, remove ballast and starter before replacement.
Applications:
1 Before installation, check whether the power is suitable. The tube must work under the right voltage according to the specification.2 Cut off the power first for safety
3 Don’t take the tube apart
4 Recommend indoor use
5 Please use it in a ventilation environment and keep it from water.
6 DO NOT connect power (positive & negative) to the two pins at one end only. If they are connected together (positive/negative), you will create a short circuit!
900mm Mini Bracket T5 LED Tube Dimension
900mm Mini Bracket T5 LED Tube Illuminance
900mm Mini Bracket T5 LED Tube Dimension
900mm Mini Bracket T5 LED Tube Packaging
Additional Information
| Payment Terms | L/C, T/T, Others |
|---|---|
| Minimum Order | 10 |
| Lead Time / Delivery Time | 10 Day(s) |
| Sample Available | YES |
| Delivery Details | Air/Sea/Express |
| FOB Port | Shenzhen |
| Loading Info | Air/Sea/Express |
| Packing Info | Exquisite carton |
| Target Market(s) | North America, Oceania, Southeast Asia, Eastern Europe, Africa(except Middle East), Hong Kong/ Macao/ Taiwan, Latin America, Japan & Korea, Mainland China, Western & Southern Europe, Northern Europe, Central & Southern Asia, Middle East |
