18W 300x300cm 3528 SMD LED Panel Light
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
Product Description
Product Description
Basic Specification
| Dimension | 300*300*15 |
|---|---|
| Material | aluminum + PMMA Lens |
| Light Source | LED Lamp |
| Voltage | 220V |
Detail Description
18W 300*300 3528 SMD LED Panel Light
Specifications:
| Total power consumption | 21W |
| LED consumption | 18W |
| Input voltage | AC90-250V, 50/60Hz |
| Power supply | external constant current |
| Lighting source | low power 3528 LEDs |
| LED quantity | 288pcs |
| Dimension | 300 mm*300mm*15mm |
| Main material | aluminum + PMMA + PC |
| Luminous flux | 1400lm |
| Color temperature | 2700-4500K, 4500-6500 K, 6500-9000K |
| Viewing angle | ≤120 ° |
| CRI | more than 70 |
| Working temperature | -20~45°C(-4~104 °F) |
| Environment humidity | less than 90 percent |
| Working environment | indoor use (applicable for dry environment) |
| Protection rating | IP44 |
| Life-span | 50,000 hours |
| Weight | 1450g (lamp),1720g (total) |
| Certification | CE, RoHS and UL pending |
| Installation | suspended,mounted |
| Warranty | 2 years |
Module
ZPM-CS4-3030-GOP18-A1 (natural white)
ZPM-CS4-3030-GOW18-A1 (warm white)
ZPM-CS4-3030-GOC18-A1 (cold white)
Features:
1. Ultra thin design, 15mm in thickness
2. Superior raw materials. Stylish everlasting color aluminum frame with advanced anodized and oxidation treatment. Modern & elegant appearance makes the ceiling more graceful
3. LED panel has Different sizes available: 300*300mm, 300*600mm.
4. Diversity in shape (square, rectangle)
Applications:
300*300mm 18W LED panel light can be extensively applied to general lighting, such as mall, store, hotel, office, supermarket, commercial building, station, warehouse, residential, parking lot, home, restaurant, railway, subway station, bank, warehouse, exhibition gallery, library, closet, factory, etc. Replace conventional fluorescent lamp or sodium lamp.The 300*300mm LED panel is energy efficient and environmentally friendly.Advantages
1 Eco-friendly green product
2 Reliable quality
3 Competitive pricing
4 Quick shipment
5 OEM & ODM orders are acceptable
6 Our experienced professionals at your service if need
18W LED panel Installation
18W LED panel Electrical Connection
300*300mm 18W LED panel Dimension
18W LED panel Iluminance
Additional Information
| Payment Terms | L/C, T/T, Others |
|---|---|
| Minimum Order | 50 |
| Lead Time / Delivery Time | 10 Day(s) |
| Sample Available | YES |
| Delivery Details | Air/Sea/Express |
| FOB Port | Shenzhen |
| Loading Info | Air/Sea/Express |
| Packing Info | exquisite carton,FCCD |
| Target Market(s) | North America, Oceania, Southeast Asia, Eastern Europe, Africa(except Middle East), Hong Kong/ Macao/ Taiwan, Latin America, Japan & Korea, Mainland China, Western & Southern Europe, Northern Europe, Central & Southern Asia, Middle East |
