Energy saving 3528 Led strips light -commercial lamp

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

Product Details

Basic Specification

Waterproof standard	IP20/IP65
Product Approvals	CE,RoHS
LED Light Source	SMD 3528
PCB Type	8mm PCB
Cuttable	Every 3 Leds
Voltage	12V
Colour	White
Light Source	LED

Detail Description

12V High Lume SMD3528 Flexible Led Strip lighting

------------Brife Specification

Energy saving 3528 Ledstrips commercial lamp

Items	Order Code	Part Number	LED Type	LED Qty	PCB Size	Packing	Power	IP Standard	Wave\\Colour Temperature
	KT-3	KT-3528W-30D-12V-8mm	3528	30leds/meter 150leds/reel	5000*8mm	5m/reel	2.4w/m	20 non-waterproof	586-590nm
	KT-3	KT-3528W-30D-12V-8mm	3528	30leds/meter 150leds/reel	5000*8mm	5m/reel	2.4w/m	65 waterproof	586-590nm

------------Picture
( All the pictures were real goods and taken by KENTO staff )

12V New Outdoor/Home SMD3528 LED Strips

Assembly Information:

The strips can be cut every 3pcs leds between the designated solder pads.
The minimum  bending radius is 3cm.
The strip can be bent at any angle to fit different needs.
With wide viewing angle, evenly illuminated effects.

Safety Information:

— The led  ribbon strips itself and all its components may not be mechanically stressed.
— Assembly must not damage or destroy conducting pads on the circuit board.
  Only qualified person should be allowed to perform installations.
— Parallel connection is highly recommended.
  Unbalance voltage drop can cause hazardous overload and damage the strips.
— Please ensure that power supply is of adequate power to operate the total load.
— When mountin on metallic or otherwise conduct surfaces,
   there need to be an electrical isolation points between strip and the mounting surface.

------------Features:
1.Various colors including single color and RGB colors
2. It is waterproof, has its own patent
3. 5m/reel for standard length, different length available
4. Solid-state, high shock / vibration resistant
5. Viewing angle is 120 degrees and voltage is 12V DC
6. Maintenance free, easy installation
7. Long life 100,000hrs+ (10+ years), white LED, 50,000hrs+

------------Applications:
1. Architectural decorative lighting
2. Accent lighting
3. Border/contour lighting
4. Emergency&security lighting
5. Auditorium walkway lighting
6. Stairway accent lighting
7. Concealed lighting
8. Backlighting for signage letters
9. Channel letter lighting
10. Cove lighting

------------Basic technical data:
1. Standard length: 5 meters/reel
2. Ribbon width: single color 12mm, RGB tri-color 14.5mm
3. Printed circuit board thickness: single color 0.25mm, RGB tri-color 0.2mm
4. Working voltage: 12V DC
5. Viewing angle: 120 degrees
6.Working current: single color 2A, RGB tri-color 3A
7. Entire ribbon LED quantity: single color 300pcs, RGB tri-color 150pcs
8. Size of smallest 3-LED unit (L x W): single color 50 x 12mm, RGB tri-color 100
x 14.5mm

------------Advantages:

1.Pretty appearance as quality
2. High efficiency, low heat, energy saving 90% compare with glass neon.
3. Long life-span (40,000-50,000hours)
4. Fashion design and different types
5. Flexible,easy to bend, easy to install by the 3M tape on the PCB back.
6. Non water-resistant, water-resistant and waterproof versions are available on request.
7.CE and RoHS certifications.
8. No risk of mercury emission, environmental protection
9. 2-3 years warranty
10.Low price,quantity production,short lead time

------------Applications:

1. Building decoration.
2. Car decoration.
3. Amusement park and theater lighting.
4. Emergency hallway lighting.
5. Archway, canopy and bridge edge lighting.
6. Shopping mall, restaurant, hotel, meeting room and advertisement lighting and decoration.

Additional Information

Payment Terms	L/C, T/T, Paypal, Others
Minimum Order	100meters
Lead Time / Delivery Time	7 Day(s)
Sample Available	YES
Delivery Details	lead time:5-10daysaccording to your quantity
FOB Port	Shenzhen
Loading Info	EXWAir transportationSea transportation
Packing Info	Anti-static bags, weight per unit: 0.31 kg, carton dimension can be adjustable according to customers\' requirements
Target Market(s)	Africa(except Middle East), Central & Southern Asia, Eastern Europe, Hong Kong/ Macao/ Taiwan, Japan & Korea, Latin America, Mainland China, Middle East, North America, Northern Europe, Oceania, Southeast Asia, Western & Southern Europe
