LR G model Truck mounted ULV Aerosol generator

Feature

l  Excellent atomization, quick diffusion, creates dense fog penetrate into spaces and lingers in air for longer time.

l  Mounted on truck, small can mount on any vehicle, machine pedestal also equipped with wheel,can pulley while spraying.

l  Equipped with remote control system to operate the unit from driver cabin, avoid exposure to chemicals.

l  Adjustable spray heads ensure spraying direction is variable.

Manual control type: Swivel 360 degree both horizontally, 180 degree vertically.

Remote control type: Automatically swivel 360 degree horizontally, 180 degree vertically.

Application

l  Can spray all type o chemicals, used for public health protection, disinfection, vector control,

pest control, crops protection,

l  Suit for spray both indoor and outdoor environment, such as in theatre, stadium, transportation center, greenhouse, garden, etc.

Technical specification

Engine Single cylinder, upright, air cooled, 4stroke diesel engine.

Power(kW/rpm)       6.3kw / 8.5hp

Start up mode Electric, 12V

Fuel tank  16L, diesel

Fan   High pressure centrifugal fan

Blower     Direct drive, positive displacement rotary type      , Air volume >30000 L/min

Air pressure(Pa)       >3500

Atomizing type         Highly speed swirl air pressure

Particle size(micron)        30< Fog VMD< 150

Flow rate 50-300 L/h, adjustable.

Standard chemicals tank 50L, optional

Dimensions (L x W x H)    66X121X117 cm

Net weight       200 kg

Packing dimension (L x W x H) 125X75X132 cm

Packing weight         272 kg
