Truck mountable ULV cold fogger 18M

Feature

l  18 HP engine power, perfect atomization, produce 95% fog droplet size under 20 micron VMD.

l  Mounted on vehicle, remote control system to operate the unit from driver cabin, avoid exposure to chemicals.

l  Sturdy construction, the unit is mounted on a solid frame with 4 shock absorbers.

l  Machine pedestal construction form Z-base rails for easier vehicle mounting.

l  Adjustable spray heads ensure spraying direction is variable.

l  Manual control type, 2 nozzles, swivel 360 degree both horizontally and vertically.

l  Remote control type, 1 nozzle, automatically swivel 360 degree horizontal, 240 degree

lvertically.

l  Live monitoring: Engine hour meter, tachometer, glycerin filler pressure gauge, and oil gauge.

Application

l  Compatible with all chemicals label for ULV use, ULV formulation can be diluted with diesel, kerosene or water, while WP-Wettable Powders can be diluted with water.

l  Used for public health protection, disinfection, vector control, pest control,

l  Suit for spray both indoor and outdoor environment, such as theatre, stadium, shopping center, transportation center, food processing plant, outside mosquito control,

Technical specification

Model       LR-18

Engine      18 hp, V-twin cylinder, electric start with oil filter

Start up    Electric start, 12V

Formulation Output 0 to 1 L/min

Particle Size     95% of fog droplet less than 20 micron VMD, recommend flow rate ULV

0.12 L/min

Formulation Tank     60 L, corrosion resistant

Fuel Tank 36 L with fuel gauge

Flush Tank         5 L, corrosion resistant

Blower     Rotary, positive displacement, 188.34 CFM/ 5.33CBM/min, pressure, 500mbar when

engine speed at 2800RPM

Dimensions (L x W x H)    130 x 111 x 92 cm

Net weight       190 kg

Dimensions (L x W x H) (Shipping data)   133 x 114 x 95 cm
