Products : Expressway car number capture camera

Expressway car number capture camera Expressway carnumbercapturecamera

●1/3"Sony Ex-View CCD

●IRCut filter

●Built-in 5-100mm ASP Auto Iris IR Lens

●650TV Line

●0.0005Lux

●User-friendly OSD Function

●Remote control (RS485 interface)

●High Speed White Balance Mode(1Field)

●114Pcs High Intensity LED's

●Super Digital Noise Reduction(SDNR)

●Outdoor Aluminium Housing

●Waterproof design(IP66)

●Recognition range up to 30m intotaldarkness

●Designedfortrafficsurveillance

●Clearly capture the number plate

when carspeed is200km/h

●NTSC/PAL System

Model Number	AP-LPR-T9
Type	WDR (D/ N)
Signal System	NTSC/PAL
Filter(Crystal)	IR Cut filter
Inage senser	1/3"Sony Ex-view CCD
Pixel	NTSC:811H×508V PAL:795H×596V
Resolution	650TV line
Mini Illumination	0.0005Lux(adjustable)114 PCs High Power IR LED ON
Vertical Frequency	NTSC:59.94Hz PAL:50.00Hz
Horizontal Frequency	NTSC:15.734KHz PAL:15.625KHz
Clock Frequency	NTSC:28.636MHz PAL:28.375MHz
Scanning System	2:1 Interlace
Sync System	Internal
S/N Ratio (AGC OFF)	more than 65db
Electronic Shutter	NTSC1/60-1/100,000SEC; PAL1/50-1/100,000SEC
Lens Driver	5-100mm ASP IR LENS(AUTO IRIS)
IR LED	114Pcs High Intensity
Recognition distance	30M
White Balance	OSD Function
Black Light Compensation	OSD Function
Auto Gain Control	OSD Function
Gamma	0.45
Video Output	1.0Vp-p(75Ω BNC)
Power Supply	DC12V/AC24V
Current Consumption	500-1900 mA(adjustable)/Max current: 2700mA
Dimension	560200160mm
Weight	4000g
Storage Temperature	-30~+60℃
Operating Temperature	-10~+45℃
