Samsung Mobile Phone Motherboard

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

Samsung mobile phone motherboard

1· UL,16949, RoHS, ISO9001

2· High layers PCB manufacturing, up to 32 layers

3· Low costs, Minimum cost for 3 prototype boards is only $84!!!

4· Fast service, Minimum lead time for bare PCB is only 2 days

5· Promptly reply, quotation will be provided in 8 working hours!

China Printed Circuit Board(PCB) Manufacturer

We are the professional PCB (1-28 layers), FPC (1-10 layers) and Rigid-Flex (1-12 layers) manufacturer.

1. Professional manufacturer of PCB and PCB assembly, specialized in single-sided PCB, double-sided PCB, multilayer PCB, PCB layout and design and PCB assembly.

2. Material Type: FR4, CEM-1, non-halogen material, Aluminium Base, Cooper Base, high frequency material ,Thick copper foil, 94-V0(HB), PI Material, High TG:SL S1000-2,ITEQ:IT180.

3. Surface treatment: HASL, HAL LF, Immersion Gold, Immersion Tin, Immersion silver, Gold Finger, OSP.

Application

Products are applied to a wide range of High-tech industries such as: LED, telecommunication, computer application, lighting, game machine, industrial control, power, automobile and high-end consumer electronics, ect. By unremitting work and effort to the marketing, products exports to American, Canada, Europe counties, Africa and other Asia-pacific countries

Advantage

1. PCB from factory directly
2. PCB which have the comprehensive quality control system
3. PCB with good price
4. PCB with quick turn delivery time from 48hours.
5. PCB with certification (ISO/UL/RoHS/SGS)
6. PCB with 10 years experience in exporting service
7. PCB is no MOQ/MOV.
8. PCB with high quality. strict test through AOI (Automated Optical Inspection),QA/QC, Flying Proble Test, E-test fixture.

Trade Term:

1. Payment: T/T, LC,Paypal.

2. Lead time: 10 working days for 100~500pcs, 15 working days for 500~2000pcs

3. Samples can be available within 6-8 working days

4. Shipping freight is quoted under your requests

5. Shipping port: Ningbo, China mainland

6. Discouts are offered based on order quantities

Service:

1. Your inquiry related to our products or prices will be replied in 24hours.

2. Well-trained and experienced staffs to answer all your enquires influent English.

3. OEM & ODM are welcomed, OEM brand is available.

4. Distributor ship is offered for your unique desigh and some our current models.

5. Protection of your sales area, ideas of design and all your private information.

PCB Production Capacity

PCB		High precision prototype	PCB bulk production
Max Layers		1-28 layers	1-14 layers
MIN Line width(mil)		3mil	4mil
MIN Line space(mil)		3mil	4mil
Min via (mechanical drilling)	Board thickness≤1.2mm	0.15mm	0.2mm
	Board thickness≤2.5mm	0.2mm	0.3mm
	Board thickness>2.5mm	Aspect Ration≤13:1	Aspect Ration≤13:1
Aspect Ration		Aspect Ration≤13:1	Aspect Ration≤13:1
Board thickness	MAX	8mm	7mm
Board thickness	MIN	2 layers:0.2mm; 4 layers:0.35mm; 6 layers:0.55mm; 8 layers:0.7mm; 10 layers:0.9mm	2 layers:0.2mm; 4 layers:0.4mm; 6 layers:0.6mm; 8layers:0.8mm
MAX Board size		610*1200mm	610*1200mm
Max copper thickness		0.5-6oz	0.5-6oz
Immersion Gold/ Gold Plated Thickness		Immersion Gold:Au,1—8u" Gold finger:Au,1—150u" Gold Plated:Au,1—150u" Nickel Plated :50—500u"
Hole copper thick		25um 1mil	25um 1mil
Tolerance	Board thickness	Board thickness≤1.0mm:+/-0.1mm 1.0mm<Board thickness≤2.0mm:+/-10% Board thickness>2.0mm:+/-8%	Board thickness≤1.0mm:+/-0.1mm 1.0mm<Board thickness≤2.0mm:+/-10% Board thickness>2.0mm:+/-8%
	Outline Tolerance	≤100mm:+/-0.1mm 100< ≤300mm:+/-0.15mm >300mm:+/-0.2mm	≤100mm:+/-0.13mm 100< ≤300mm:+/-0.15mm >300mm:+/-0.2mm
	Impedance	±10%	±10%
MIN Solder mask bridge		0.08mm	0.10mm
Plugging Vias capability		0.25mm--0.60mm	0.70mm--1.00mm
