3G GPS Anti-Quake Mobile DVR

Features:

1) Transmission:3G(EVDO/WCDMA);
2) Built-in GPS module(Google Map),
3) Supports remote view with IE (Internet Explorer)

Specification:

Model No.	IGV-MB3104GPS-3G
Video Compression	H.264
Video System	NTSC / PAL
Operation System	Linux2.6
Audio Compression	8kHz*16bit ADPCM
Audio Input/Output	BNC 4-channel inputs/1-channel output
Display Frame Rate	NTSC:120 fps @ D1/ PAL:100 fps @ D1
Playback Resolution	PAL:CIF(352×288),HD1(704×288),D1(704×576) NTSC:CIF(352×240),HD1(704×240),D1(704×480)
Total Recording Frame Rate	PAL: 25 fps@D1, 50 fps@HD1, 100 fps@CIF NTSC: 30 fps@D1, 60 fps@HD1, 120 fps@CIF
Recording Modes	Always/ Schedule / Motion detection / Sensor triggered
Recording Pack Time	15/30/45/60mins selectable
HDD Interface	Supports up to 1 500GB 2.5 inches SATA HDD
Network Interface	RJ45 Ethernet, 3G EVDO or WCDMA module (Optional)
Network Protocol	TCP/IP, UDP, DHCP, DDNS and PPPoE
Network Function	Supports remote view with IE (Internet Explorer)
USB 2.0	USB mouse USB flash disk & USB hard disk (backup, upgrade)
Playback Modes	Normal play, fast forward, fast rewind, frame by frame
GPS	Supports GPS information burned in stream (Optional)
Backup	AVI file via USB flash disk, USB hard disk & Network
Alarm Modes	Motion detection, sensor triggerd, video loss, HDD error, HDD full
Sensor & Alarm I/O	4 sensor inputs / 2 alarm outputs
Power Supply	DC 9~32V
Power Consumption	10~15W
Working Temperature	-10℃ to +40℃
Working Humidity	10% to 90%
Dimension(W×D×H)	21720970.4mm

3G GPS Anti-Quake Mobile DVR
