hot sales P10 indoor led display
- Payment Type:
- T/T
- Incoterm:
- EXW
- Min. Order:
- 1 Square Meter
- Min. Order:
- 1 Square Meter
- Delivery Time:
- 20 Days
- Transportation:
- Ocean, Air
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | Guangdong, China (Mainland) |
|---|---|
| Payment Type: | T/T |
| Incoterm: | EXW |
| Certificate: | CE,FCC |
| Transportation: | Ocean,Air |
hot sales P10 indoor led display
Product Advantages:
1.Price Advantage
We use full automatic equipment, so each month; we productivity can up to 1000sqm,
In this case, our raw material purchase price is lower than others.
2.Good quality raw material
LED: Adopting low current, high brightness LED, body antistatic >1000V, LED scope wavelength with in 5nm, so the screen with reliable performance, good consistency, fast response time and long life time.
Mask: All designed by ourselves, using good PC material, not easy to deform
3.Convenient installation
We prepare a full-set installation manual and free training, which will make you easy to install and operate the screen.
4.Good after-sale service
Two years warranty, lifetime maintain, During the warranty ,all broken parts caused by the quality problem could be replaced by us free of charge
Application:
Indoor full color LED display could be used in indoor environment such as municipal mansion, enterprise hall, show room, cinema, stage, with various real-time signal sources and the SMD encapsulation technology, its purpose is to play the important news or events or TV program etc
|
Item |
Technical Specification |
|
Pixel |
Pixel pitch: 10mm |
|
Pixel configuration: 1R1G1B |
|
|
Brightness: Red: 1000mcd Green: 2300mcd Blue: 600mcd |
|
|
Module |
Module size: 160mm*160mm |
|
Cabinet size: 960mm*960mm×100mm |
|
|
Cabinet |
Cabinet resolution: 96*96 pixels |
|
Cabinet material: Iron |
|
|
Gross weight: 55kg |
|
|
Module quantity: 36 pcs= 6(w) x 6(h) |
|
|
Power consumption : Max.:1000WSqm Avg: 600W/Sqm |
|
|
Brightness: 800cd/m² |
|
|
IC driver: MBI 5026 |
|
|
Density: 10000 pixel/m² |
|
|
Whole display flatness: ≤ 1mm juncture |
|
|
Best view distance: ≥ 10m |
|
|
Viewing angle: Horizontal: 120° Vertical: 60° |
|
|
Humidity(RH): 90~95% |
|
|
Working temperature: from -30°C to 60°C |
|
|
Working voltage: AC220V/110V±10% |
|
|
Refresh frequency: 2400Hz(Zdec) ≥ 300Hz(Linsn) |
|
|
Frame rate: ≥ 60Hz |
|
|
Protection grade: IP64 |
|
|
MTBF: More than 10000hrs |
|
|
Control system: Linsn |
|
|
Control system |
Signal interface: DVI |
|
Communication distance: Internet cable: ≤120m / Fiber cable: 1000m |
|
|
Systems operating platforms : XP,WINDOWS(WIN95,WIN98,WIN2000) |
