led 30x30 ceiling panel light 18W 160pcs 3014smd led
- Min. Order:
- 1
- Min. Order:
- 1
- Delivery Time:
- 5 Days
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | Shenzhen |
|---|---|
| Supply Ability: | 200 |
| Certificate: | CE ROHS FCC |
new! led 30x30 ceiling panel light 18W 160pcs 3014smd led AC85-265V white/warm white color free shipping
Technical Specification:
18W 295x295x12.5mm Slim LED Light Panel
1. LED source: 160pcs High birght SMD3014
2. Led quantity(pcs):160cs SMD3014
3. Power(W):18W
4. Luminous Flux: 1000-1100lm for white
5. Bean angle:180degee
6. Material: aluminum alloy+acrylic
7. Color:R/G/B/Y/PW/WW/CW
9. Ambient Temperaturee:-40~50degree
10. Input voltage: 85-265V AC, Work voltage: 30-40VDC
|
|
|
|
|
NO. |
Specification |
|
|
1 |
Input Voltage |
AC85-265V |
|
2 |
Power Consumption |
18W |
|
3 |
Luminous Flux |
>1100Lm (Cool white) >1000Lm (Natural white) >900Lm (Warm white) |
|
4 |
Color Temperature |
2700-3300K(Warm white) 4000-5000K (Natural white) 6000-7000K(Cool white) |
|
5 |
Life Time |
>50,000 Hour |
|
6 |
Luminosity(1m height) |
>280Lux(1.0Meter, cool white) >250Lux(1.0Meter, Natural white) >200Lux(1.0Meter, warm white) |
|
7 |
Certifications |
CE, ROHS |
|
8 |
Weight |
2KGS |
|
9 |
Size |
35*7*40cm |
|
10 |
Fixing Ways |
In-built, Mounting, Suspending |
Feature:
18W 295x295x12.5mm Slim LED Light Panel
1. Use advanced side-lighting technology
2. Professional heat sinking design
3. 70%-80% energy saving than fluorescent lights
4. no flickering
5. No RF interference
6. No UV radiation
7. Easy installation and maintenance-free
8. Instant soft start
9. Proprietary design for excellent thermal management with aluminum and acrylic housing
10. Mounting: combine SMD LED light source with light fixtures, mount directly. spring mounting/ceiling mounting
Application:
Hotels, Conference / Meeting rooms, Factories & Offices
Residential / Institution Buildings, Schools, Colleges & Universities, Supermarket Lighting
Attention:
1 Use indoor or some place where no water, don`t put them in wet or dam place
2 Please check the local voltage compliance product requirements
3 Installed in a well-ventilated place to ensure appropriate environmental temperature
4 When installation, try to avoid the minefields, strong magnetic field and high-pressure region
5 Always turn power off at the circuit breaker before rewiring your fixture
Installation:
1.Turn off the power.
2.Connect the commercial power (85V-265V) with the input of the matched power supply, make sure that no copperware exposed.
3.Connect matched power supply and panel light together through the DC plug.
Insure safe connection.
4.Fix the panel light and power supply at suitable place.
5.Turn on the power, can immediately use.
