electronic signs led display
- Min. Order:
- 1
- Min. Order:
- 1
- Delivery Time:
- 20 Days
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | shenzhen china |
|---|---|
| Certificate: | CE |
- CreateLED AirLED-15 LED display is available for outdoor rental and fixed installations. It is the truly waterproof LED display panel, combining ultra-lightweight design with remarkable high-performance, this LED display will be the ideal solution for outdoor use with high performance needed.
- Using breakthrough approach in thermal management, special truly waterproof LED technologies and innovative system design, the super bright AirLED-15 1R1G1B vertical arrangement pixel configuration brings true possibilities of ensuring the sharpest image and superb video quality, brilliant enough for outdoor events and shows.
-
Key Benefits
1. Ultra-light weight and slim design, front or back accessible for maintenance purposes.
2. Quick lock system allowing fast rigging.
3. Standard panel design makes stocking, transportation, construction, spare parts and maintenance easy and simple.
4. Flexible power supply box allowing easy maintenance.
5. Excellent water-proof panel with IP65 front and IP54 back.
6. Wide view angle and no left-right colour shift aberration.
7. Daylight viewable. -
Ideal For: Rental use
Stage EventsConcert TouringAdvertisingPub & ClubTheater and ArtsTV StudiosCar Shows
MechanicalModule size: 250mm x 250mm
Panel size: 500mm x 500mm x 115mm
Panel weight: 16kg
Weight per m2: 64kg
Precision Extruded Aluminum Section Design
Video DisplayLED type: 1R1G1B
Resolution: 32 x 32 pixel/panel
Pixel pitch: 15.6mm
LED population: 4,096 LED/m2
Brightness: 5,500 Nits
Drive method: 1/2 scan method
Lifetime(50% brightness): 100,000 h
Colors: 281 trillion
Gray scale: 16 bit
Refresh rate: 1,200~4,000 Hz
Viewing angle: H:140°, V:50°
Dead Pixel Ratio: 0.0003
ElectricalPower supply: AC 220-240 V, 50/60 Hz
Power consumption: Avg 100 W/panel
MTBF ≥ 1,000 H
Ambience working temperature: -20~55
Ambience humidity: 85% at 25, 65% at 40
Control SystemSender Box input: USB connector
Sender Box output: RJ45 connector
Connection between PC and Sender Box: USB cable
Supported video input: DVI/HDMI/SDI
Software functions: display configuration, intensity adjustment, color calibration, content management, and system settings.
